Motor-Driven Ball Screw Linear Drive Mechanism

Application Industries:

Automotive part Packaging Medical
This figure is a case of a linear drive
mechanism driven by a stepper motor, which is Reference price
widely used in industrial automation production
such as automotive parts manufacturing,
packaging, and medical care.

01 Motor ×1 P.216 02 Rolled Ball Screw ×1 P.37

Motor+Driver42Series Shaft Dia. 10
Body Length 31mm Lead 4mm
Number of Leads 4 Threaded Shaft
Holding Torque 0.22N·m Overall Length 450mm

188.74 585.77

MYR/set MYR/pcs

03 Coupling ×1 P.236

Slit Shaped
O.D. (П) 20mm
Shaft Hole Dia. 1 (П)6mm
Shaft Hole Dia. 2 (П)8mm

31.93

MYR/pcs
