Page 723 - MiSUMi FA Mechanical Components Economy Series

Blind Joints, Pre-Assembly Insertion Center Joint Kits For Aluminum Frames

Connection Slot Width Series 8-90
48 %
Saving Up to
vs Standard Type
Shipping
from
9.50 MYR 1 day

For price with different specification, please check our website

15
D1 L1
L2
D1 Accessories / Safety Fences Aluminum Frames / Related

H
T D2 D3

L Frames Aluminum

.Material : Carbon Steel P.687
4Surface Treatment : Zinc Plating
How to create a Connection Slot Direction Dimension
model Width Series L L1 L2 H D1 D2 D3 T Sheet Metal Brackets/Joints/
8-90 90°
MISUMI WEB 33 18.5 5 20 П11 П6.6 П15.8 7.8 P.704
1.Search this keyword
blind joint 8-180 180°
2.Select Economy series
Brand 10-90 90° Nuts/Bolts
MISUMI
Economy series 46 26.5 6 28 П17 П9.7 П19.5 9.8
10-180 180°
P.723
How to create Configure Clear All
a model Step Search on MISUMI official website Step Select Brand Brand
1 blind joint 2 MISUMI MISUMI Plate Accessories/
Economy Series
Input the keyword and search on the website
Economy series
P.732
Example

180° Direction 90° Direction Fences Safety
P.743

Safety Fences
Accessories for
P.750
Connector installation diagram
