Quality Assurance Economy Series
Handles
2 Product Features of MISUMI Economy series Round Bar Handles
· MISUMI Economy series round bar handle is processed with round steel, which has better overall roundness
than the rolled steel used in the generic products in the market. With better roundness, the tolerance can be
better controlled in the subsequent tapping process.
Cases of poor quality of generic products in the market MISUMI Economy series MISUMI Economy series (full inspection)
Due to the
insufficient High roundness, Full inspection to Handles
guarantee
roundness of the without bias. mounting pitch.
bar, the opening is
severely biased. P.825
Standard inner
diameter, and
The inner diameter guaranteed
is too large, which allowable load.
can easily lead to Hinges
slippery thread. * Full fixture inspection to ensure the mounting pitch
P.841
2 Product Features of MISUMI Economy series Embedded Handles
· Screws and nuts are fixed by riveting process. Compared with the generic products in the market fixed by Knobs
welding, the mounting pitch is better controlled, and the problem of screws falling off due to poor welding is
also completely solved. P.858
Cases of poor quality of generic products in the market MISUMI Economy series rail Linear slide
Fix by welding. It is fixed by riveting,
Unable to control the mounting which completely solves P.876
hole distance. the problem of poor 17
Poor welding occurs frequently, welding.
causing screws to fall off and Riveting method can be
cannot be installed. controlled the mounting
pitch more effectively.
Easy installation Knobs / Slide Rails Handles / Hinges /
2 Product Features of MISUMI Economy series Resin Handles
· The reinforcement is added at the position where it is easy to shrink and deform, so that the problem of
shrinkage and deformation after forming can be alleviated, the accuracy of mounting pitch dimension is
improved, and the installation is more convenient.
Cases of poor quality of generic products in the market MISUMI Economy series
The reinforcement is added to greatly alleviate
No reinforcement, with forming shrinkage the problem of shrinkage and deformation,
Severely deformed, and unable to install
and the installation is convenient.
* There is no reinforcement for goods with the mounting pitch of 90mm.
* Generic products in the market are similar products randomly purchased by our company from online or offline markets.
