P. 170

iglidur  J                                                                                                                                                                                                              iglidur  J
              ®
                                                                                                                                                                                                                                      ®
          +90°C                                                                                                                                                                                                                   +90°C
          35MPa                                                                                                                                                                                                                   35MPa
                      Bearing technology | Plain bearings | iglidur  J                                                              Product range
                                                                                                    ®
          Sleeve bearings (form S)                                                                                                  d1         d1      d2     b1   Part No.             d1        d1       d2    b1   Part No.

                                                                                                                                            Tolerance 3)      h13                              Tolerance 3)      h13
                                                                              f1  30°
                                                                                                                                    [mm]               [mm]  [mm]                       [mm]              [mm]  [mm]
                                                                                                                                    12.0               14.0   6.0  JSM-1214-06          20.0    +0.020    23.0  25.0  JSM-2023-25
                                                                                                                                    12.0               14.0   8.0  JSM-1214-08          20.0    +0.104    23.0  30.0  JSM-2023-30
                                                                d1  0.5           d2                                                12.0               14.0   9.0  JSM-1214-09          20.0              26.0   6.0  JSM-2026-06
                                                                                                                                    12.0     +0.032    14.0  10.0  JSM-1214-10          20.0    +0.065    26.0  20.0  JSM-2026-20
                                                                 30°
                                                                         b1                                                         12.0     +0.102    14.0  12.0  JSM-1214-12          20.0    +0.195    26.0  25.0  JSM-2026-25
                                                                                                                                    12.0               14.0  15.0  JSM-1214-15          20.0              26.0  30.0  JSM-2026-30
                                                                                                                                    12.0               14.0  20.0  JSM-1214-20          21.0              24.0  12.0  JSM-2124-12
                                                                                                                                    12.0     +0.050    16.0  12.0  JSM-1216-12          22.0              25.0  15.0  JSM-2225-15
                                                             2)  Thickness < 0.6mm: chamfer = 20°
          Chamfer in relation to d1                                                                                                 12.0     +0.160    16.0  17.0  JSM-1216-17          22.0              25.0  20.0  JSM-2225-20
          d1 [mm]   Ø 1-6     Ø 6-12   Ø 12-30    Ø > 30           Dimensions according to ISO 3547-1 and                           13.0               15.0  10.0  JSM-1315-10          22.0              25.0  25.0  JSM-2225-25
          f1 [mm]    0.3       0.5        0.8       1.2            special dimensions                                               13.0               15.0  20.0  JSM-1315-20          22.0              25.0  30.0  JSM-2225-30
                                                                                                                                     13.0              16.0  18.5  JSM-1316-185         23.0              26.0  12.0  JSM-2326-12
               Order example: JSM-0104-02 – no minimum order quantity.                                                               14.0              16.0   5.0  JSM-1416-05          24.0              27.0  15.0  JSM-2427-15
               J iglidur  material S Cylindrical M Metric 01 Inner Ø d1 04 Outer Ø d2 02 Total length b1                             14.0    +0.032    16.0   8.0  JSM-1416-08          24.0    +0.040    27.0  20.0  JSM-2427-20
                      ®
                                                                                                                                     14.0    +0.102    16.0  10.0  JSM-1416-10          24.0              27.0  25.0  JSM-2427-25
                                                                                                                                     14.0              16.0  15.0  JSM-1416-15          24.0    +0.124    27.0  30.0  JSM-2427-30
           d1        d1       d2    b1   Part No.             d1        d1       d2    b1   Part No.                                 14.0              16.0  20.0  JSM-1416-20          24.0              27.0  46.0  JSM-2427-46
                  Tolerance 3)      h13                              Tolerance 3)      h13                                           14.0              16.0  25.0  JSM-1416-25          25.0              28.0  12.0  JSM-2528-12
           [mm]              [mm]  [mm]                       [mm]              [mm]  [mm]                                           14.0              18.0  18.0  JSM-1418-18          25.0              28.0  15.0  JSM-2528-15
           1.5     +0.014    4.0    2.0  JSM-0104-02          6.0     +0.020     8.0  10.0  JSM-0608-10                              14.0    +0.050    20.0  20.0  JSM-1420-20          25.0              28.0  20.0  JSM-2528-20
           2.0     +0.054    3.5    7.0  JSM-0203-07                  +0.068                                                                 +0.160                                     25.0              28.0  25.0  JSM-2528-25
           2.0     +0.020    5.0    2.5  JSM-0205-02          6.0     +0.030     9.0   6.0  JSM-0609-06                              15.0              17.0   6.0  JSM-1517-06          25.0              28.0  30.0  JSM-2528-30
           2.5     +0.080    6.0    2.5  JSM-0206-02          6.0     +0.105    10.0  10.0  JSM-0610-10                              15.0              17.0  10.0  JSM-1517-10          25.0              28.0  60.0  JSM-2528-60
           3.0     +0.014    4.5    5.0  JSM-0304-05          7.0                9.0   5.0  JSM-0709-05                              15.0              17.0  12.0  JSM-1517-12          25.0              30.0  40.0  JSM-2530-40
           3.0     +0.054    4.5    9.0  JSM-0304-09          7.0                9.0   7.0  JSM-0709-07                              15.0              17.0  15.0  JSM-1517-15          25.0    +0.065    32.0  25.0  JSM-2532-25
           3.0               5.0    4.0  JSM-0305-04          7.0                9.0   9.0  JSM-0709-09                              15.0              17.0  20.0  JSM-1517-20          25.0    +0.195    32.0  32.0  JSM-2532-32
           3.0     +0.020    7.0   14.0  JSM-0307-14          7.0                9.0  12.5  JSM-0709-125                             15.0    +0.032    17.0  25.0  JSM-1517-25          25.0              32.0  35.0  JSM-2532-35
           3.0     +0.080    8.0    4.0  JSM-0308-04          8.0     +0.025    10.0   3.0  JSM-0810-03                              15.0    +0.102    18.0  10.0  JSM-1518-10          26.0              30.0  20.0  JSM-2630-20
           3.0               8.0    5.0  JSM-0308-05          8.0     +0.083    10.0   4.0  JSM-0810-04                              16.0              18.0  10.0  JSM-1618-10          27.0    +0.040    30.0  20.0  JSM-2730-20
           4.0               5.5    4.0  JSM-0405-04          8.0               10.0   6.0  JSM-0810-06                              16.0              18.0  12.0  JSM-1618-12                  +0.124
           4.0               5.5    6.0  JSM-0405-06          8.0               10.0   8.0  JSM-0810-08                              16.0              18.0  15.0  JSM-1618-15          28.0    +0.065    32.0  20.0  JSM-2832-20
           4.0     +0.020    5.5    8.0  JSM-0405-08          8.0               10.0  10.0  JSM-0810-10                              16.0              18.0  20.0  JSM-1618-20          28.0    +0.195    32.0  25.0  JSM-2832-25
           5.0     +0.068    7.0    4.6  JSM-0507-046         8.0               10.0  12.0  JSM-0810-12                              16.0              18.0  25.0  JSM-1618-25          28.0              32.0  30.0  JSM-2832-30
           5.0               7.0    5.0  JSM-0507-05          8.0               10.0  16.0  JSM-0810-16                              16.0    +0.050    20.0  16.0  JSM-1620-16          30.0              34.0  20.0  JSM-3034-20
           5.0               7.0   10.0  JSM-0507-10          8.0     +0.040    12.0  10.0  JSM-0812-10                              16.0    +0.160    22.0  16.0  JSM-1622-16          30.0    +0.040    34.0  25.0  JSM-3034-25
           5.0               7.0   14.0  JSM-0507-14          8.0     +0.130    12.0  12.0  JSM-0812-12                              16.0              22.0  20.0  JSM-1622-20          30.0    +0.124    34.0  30.0  JSM-3034-30
                   +0.020                                     9.0               11.0  10.0  JSM-0911-10                              17.0              19.0   6.0  JSM-1719-06          30.0              34.0  40.0  JSM-3034-40
           5.0               7.0   15.0  JSM-0507-15
                   +0.080                                     10.0              12.0   5.0  JSM-1012-05                              18.0              20.0  10.0  JSM-1820-10          30.0    +0.065    38.0  40.0  JSM-3038-40
                   +0.030                                     10.0              12.0   6.0  JSM-1012-06                              18.0    +0.032    20.0  15.0  JSM-1820-15                  +0.195
           5.0               8.0    5.0  JSM-0508-05
                   +0.105                                     10.0              12.0   8.0  JSM-1012-08                              18.0    +0.102    20.0  20.0  JSM-1820-20          32.0              36.0  20.0  JSM-3236-20
           6.0               7.0    3.0  JSM-0607-03          10.0    +0.025    12.0  10.0  JSM-1012-10                              18.0              20.0  25.0  JSM-1820-25          32.0              36.0  30.0  JSM-3236-30
                                                                      +0.083
           6.0     +0.010    7.0    5.0  JSM-0607-05          10.0              12.0  11.0  JSM-1012-11                              19.0              22.0  14.0  JSM-1922-14          32.0              36.0  40.0  JSM-3236-40
           6.0     +0.058    7.0    8.0  JSM-0607-08          10.0              12.0  12.0  JSM-1012-12                              20.0              22.0  20.0  JSM-2022-20          32.0    +0.050    37.0  25.0  JSM-3237-25
           6.0               7.0   12.5  JSM-0607-12.5        10.0              12.0  15.0  JSM-1012-15                              20.0    +0.040    22.0  30.0  JSM-2022-30          32.0    +0.150    38.0  50.0  JSM-3238-50
           6.0               7.0   14.0  JSM-0607-14          10.0              12.0  20.0  JSM-1012-20                              20.0    +0.124    23.0  10.0  JSM-2023-10          35.0              39.0  20.0  JSM-3539-20
           6.0     +0.020    8.0    4.3  JSM-0608-043         10.0    +0.040    14.0  10.0  JSM-1014-10                              20.0              23.0  15.0  JSM-2023-15          35.0              39.0  30.0  JSM-3539-30
           6.0     +0.068    8.0    6.0  JSM-0608-06          10.0    +0.130    14.0   16.0  JSM-1014-16                             20.0              23.0  20.0  JSM-2023-20          35.0              39.0  40.0  JSM-3539-40
           6.0               8.0    8.0  JSM-0608-08                                                                                                                                    35.0              39.0  50.0  JSM-3539-50

          3)  After press-fit. Testing methods, page 57                                                          ASEAN 09/2023   ASEAN 09/2023  3)  After press-fit. Testing methods, page 57
          168   3D-CAD, finder and service life calculation ... www.igus-asean.com/J                                                                            Lubrication-free made easy ... from stock ... no minimum order quantity  169
