Page 374 - IGUS Bearing

iglidur C500 iglidur C500
®
®
+250°C +250°C
80MPa 80MPa
Bearing technology | Plain bearings | iglidur C500 Technical data
®
General properties Testing method

Density g/cm³ 1.37 -100°C up to
Ø Colour magenta +250°C
6.0-40.0mm
Max. moisture absorption at +23°C/50% r.h. % weight 0.3 DIN 53495
Max. moisture absorption % weight 0.5
Coefficient of friction, dynamic, against steel µ 0.07-0.19 80MPa
pv value, max. (dry) MPa · m/s 0.70
Also available
as: Mechanical properties
High temperature endurance runner Flexural modulus MPa 3,300 DIN 53457
Flexural strength at +20°C
100
DIN 53452
MPa
Extreme wear and media resistance up to +250°C Compressive strength MPa 110
Bar stock, Max. permissible surface pressure (+20°C) MPa 80
round bar
Page 743 Shore D hardness 80 DIN 53505
iglidur C500 can be used up to +250°C and is extremely media-resistant (even in cleaning processes
®
using hydrogen peroxide). It is also wear-resistant and has low coefficient of friction. Also suitable Physical and thermal properties
for various special designs. The colour shows the use under extreme environmental influences. Max. application temperature long-term °C +250
Max. application temperature short-term °C +300 FOOD
● High temperature resistance Min. application temperature °C -100
Bar stock, ● Resistant to water vapour Thermal conductivity W/m · K 0.24 ASTM C 177
plate -1 -5
Page 773 ● Low coefficient of friction Coefficient of thermal expansion (at +23°C) K · 10 9 DIN 53752
● Lubrication-free Electrical properties
● High wear resistance Specific transitional resistance Ωcm > 10 14 DIN IEC 93
● High media resistance Surface resistance Ω > 10 13 DIN 53482
● Maintenance-free Table 01: Material properties
tribo-tape liner
Page 781 Typical application areas iglidur C500 is a member of the family of extremely media Resistance to weathering
®
®
®
● Plant construction and temperature-resistant iglidur materials X, X6 and iglidur C500 plain bearings are resistant to weathering.
● Valves A500. This material is characterised by improved wear The material properties are slightly affected. Discolouration
● Chemical industry resistance and increased design freedom. occurs.
● Process technology
Moisture absorption Mechanical properties
Guide rings
®
Page 641 The moisture absorption of iglidur C500 plain bearings is When temperatures increase, the compressive strength
below 0.3% weight in ambient conditions. The saturation of iglidur C500 plain bearings decreases. Diagram 02
®
Descriptive technical specifications limit submerged in water is 0.5% weight. shows this inverse relationship. However, at an operation
Wear resistance at +23°C – + temperature of +200°C the permissible surface pressure
Vacuum is close to 20MPa. The maximum recommended surface
Wear resistance at +90°C – +
In vacuum, any present moisture is released as vapour. pressure is a mechanical material parameter. No conclusions
Two hole Wear resistance at +150°C – + The use in vacuum is generally possible. regarding the tribological properties can be drawn from
flange
bearings this.
Page 667 Slide property – +
Radiation resistance Diagram 03 shows the elastic deformation of iglidur C500
®
Wear resistance under water – + iglidur C500 withstands neutron and gamma particle under different loads. At the maximum recommended
®
radiation without detectable losses of its excellent mechanical surface pressure of 80MPa, the deformation is less than
Media resistance – +
properties. Plain bearings made from iglidur C500 4.5%.
®
Moulded Resistant to edge pressures – + are resistant up to a radiation intensity of 3 · 10² Gy. Surface pressure, page 45
special parts
Page 696 Resistant to shock and impact loads – +
Dirt resistance – +

®
igubal Online product finder Online service life calculation
spherical balls
Page 993 www.igus-asean.com/iglidur-finder www.igus-asean.com/iglidur-expert ASEAN 09/2023 ASEAN 09/2023
