drylin drylin
®
®
®
®
stainless drylin SHT linear modules | Product range drylin SHT linear modules | Product range stainless
steel steel
Stainless-steel linear modules Hygienic design
● Corrosion-resistant carriages Order key Order key
and shaft end supports made of
stainless steel Type Size Options Type Size Shaft Option
● High grade stainless steel shafts
(AISI 440B)
● Stainless steel lead screw
● Temperature-resistant
● Up to +180°C with iglidur X Stainless steel Bearing material Shaft material
®
● Food-compliant with Standard Installation size Shaft material Hygienic design
iglidur A180 d l2 Easily cleaned solution Flexible
®
● Can be configured online as ●
E1
T E2 d2 ● Wide gaps
SHTC compact version l + stroke
● Materials: plastic and stainless steel
®
● Lead screw nuts made of FDA-compliant iglidur A180
d l2
● Accessories available u Page 613
T E3 E2 d2 E1
lt Al lt I + Hub
tk sg ha f
ts E3
kt lt Al lt d
tk sg
H ts
kt kq ha I2
H tg s
R ha E1 d2 E1 R A
f kq sk
A R tg s
f sk Øts
A
Technical data
Øts d
Part No. Max. Aluminium shaft Steel shaft Max. static load capacity lt lt
AI H
stroke length addit. addit. E2
Weight Weight axial radial
(per 100mm) (per 100mm)
[mm] [kg] [kg] [kg] [kg] [N] [N]
SHT-ESJ-08 300 0.24 0.05 0.27 0.1 100 360
SHT-ESJ-12 750 1.1 0.1 1.3 0.2 700 2,800 The lead screw linear unit can be delivered
SHT-ESJ-20 1,000 3.2 0.3 3.9 0.6 1,600 6,400 with complete FDA-compliant materials.
SHT-ESJ-30 1,250 8.6 0.6 10.9 1.4 2,500 10,000

Dimensions [mm] Dimensions [mm]

Part No. A AI H E1 E2 E3 I R f lt tk ts Part No. A Al H E1 E2 I R f It ts d T I2 d2 ha
-0.3 -0.3 ±0.15 ±0.15 ±0.15 -0.3 -0.3 ±0.15 ±0.15
SHT-ESJ-08 65 65 23 52 55 55 96 32 1.5 15.5 10 5.5 SHTC-20-EWM-HYD 130 36 48 108 115 108 72 2 36 9.0 20 Tr18x4 26 12 h9 23
SHT-ESJ-12 85 85 34 70 73 73 145 42 2.0 30.0 11 6.6
SHT-ESJ-20 130 130 48 108 115 115 202 72 2.0 36.0 15 9.0
SHT-ESJ-30 180 180 68 150 158 158 280 96 4.0 50.0 20 13.5

Part No. tg kt Øs sk sg kq d T l2 d2 ha
±0.1 Standard
SHT-ESJ-08 M6x8 7.0 4.2 8 M5 4.6 8 Tr6x2 17 Tr6x2 13
SHT-ESJ-12 M8x18 6.4 6.3 10 M6 6.0 12 Tr10x2 17 Tr10x2 92) 18
SHT-ESJ-20 M10x23 8.6 6.4 11 M8 7.0 20 Tr18x4 26 12h9 23
SHT-ESJ-30 M16x40 12.6 11.0 18 M12 10.6 30 Tr24x5 38 14h9 36

92) Lead screw end unmachined ASEAN 09/2023 ASEAN 09/2023

342 Online tools and more information u www.igus-asean.com/drylin-SHT 3D CAD files, prices and delivery time online u www.igus-asean.com/drylin-SHT 343
