drylin W drylin W
®
®
®
®
profile drylin W profile guides | Product range drylin W profile guides | Product range New profile
guides guides
Pillow blocks, square, made from zinc die-casting or aluminium Pillow blocks, square, for narrow assemblies
Order key - pillow block Order key - pillow block

Type Size Type Size

Options:
Blank: Fixed bearing
LLY: Floating bearing in
y-direction

drylin ® W square Standard AL: Pillow block made drylin ® W square Narrow Standard
z-direction
Suitable mounting plate Liner material iglidur ® J200 Pillow block, LLZ: Floating bearing in Liner material iglidur ® J200 Pillow block, Aluminium
u Page 130 Size from aluminium Size

Technical data and dimensions [mm] C1
C3
C1 A3 C1 A4
Part No. Floating Floating Weight B C1 C3 A3 K2 K3 Static load capacity C3 A3 C3 A4
bearing bearing for Coy Coz+ Coz– A3 A4
countersunk
clearance direction [g] -AL head screw [N] [N] [N]
WJ200QM-01-06 – – 16 7 18.0 19 10 4.5 M4 M3 420 420 140
WJ200QM-01-06-AL – – 16 7 18.0 19 10 4.5 M4 M3 420 420 140
WJ200QM-01-06-LLY ± 0.5 y / z 16 7 18.0 19 10 4.5 M4 M3 420 420 140
WJ200QM-01-06-LLZ ± 0.5 y / z 16 7 18.0 19 10 4.5 M4 M3 420 420 140 B
B
WJ200QM-01-10 – – 41 21 26.0 29 16 6.5 M6 M5 1,200 1,200 250 K2 B K2
WJ200QM-01-10-AL – – 41 21 26.0 29 16 6.5 M6 M5 1,200 1,200 250 K2
WJ200QM-01-10-LLY ± 0.7 y / z 41 21 26.0 29 16 6.5 M6 M5 1,200 1,200 250 H H ! Coz- y y x
H x z
WJ200QM-01-10-LLZ ± 0.7 y / z 41 21 26.0 29 16 6.5 M6 M5 1,200 1,200 250 ! Coz- z
WJ200QM-01-16 – – 100 51 34.5 36 18 9.0 M8 M6 2,100 2,100 400
WJ200QM-01-16-AL – – 100 51 34.5 36 18 9.0 M8 M6 2,100 2,100 400
WJ200QM-01-16-LLY ± 1.0 y / z 100 51 34.5 36 18 9.0 M8 M6 2,100 2,100 400
WJ200QM-01-16-LLZ ± 1.0 y / z 100 51 34.5 36 18 9.0 M8 M6 2,100 2,100 400 Technical data and dimensions [mm]
WJ200QM-01-20 – – 190 104 42.5 45 27 9.0 M8 M6 3,200 3,200 500 Part No. Weight B C1 C3 A3 A4 K2 H Static load capacity
WJ200QM-01-20-AL – – 190 104 42.5 45 27 9.0 M8 M6 3,200 3,200 500 ±0.25 Coy Coz+ Coz–
WJ200QM-01-20-LLY ± 1.0 y / z 190 104 42.5 45 27 9.0 M8 M6 3,200 3,200 500 [g] [N] [N] [N]
WJ200QM-01-20-LLZ ± 1.0 y / z 190 104 42.5 45 27 9.0 M8 M6 3,200 3,200 500 WJ200QMS-01-06-AL New 6.3 18 19 10 13.5 3.50 M4 14 210 140 210
WJ200QM-01-25 – – 435 212 52.5 58 36 11.0 M10 M8 4,800 4,800 950 WJ200QMS-01-10-AL New 17.1 23 29 16 18.5 4.75 M6 20 600 250 600
WJ200QM-01-25-AL – – 435 212 52.5 58 36 11.0 M10 M8 4,800 4,800 950 WJ200QMS-01-16-AL New 43.1 35 36 18 28.5 7.25 M8 27 1,050 400 1,050
WJ200QM-01-25-LLY ± 1.0 y / z 435 212 52.5 58 36 11.0 M10 M8 4,800 4,800 950 WJ200QMS-01-20-AL New 90.1 42 45 27 35.0 9.00 M8 36 1,600 500 1,600
WJ200QM-01-25-LLZ ± 1.0 y / z 435 212 52.5 58 36 11.0 M10 M8 4,800 4,800 950 WJ200QMS-01-25-AL New 182.4 52 58 36 43.0 10.75 M10 45 2,400 950 2,400

Order example: WJ200QM-01-06: Pillow block, square
WJ200QM-01-06-LLZ: Pillow block, square, with floating bearing in z-direction
WJ200QM-01-06-AL: Pillow block, square, made from aluminium

Can be combined with: Can be combined with:

WSQ-… WSQ-… WSX-... ASEAN 09/2023 ASEAN 09/2023 WSQ-… WSQ-… WSX-...
