triflex R trifl ex R | RSP retraction system
®
®
RSP
System design with matching e-chains ®
Matching trifl ex R e-chain for RSP
®
®
TRC .RSP.XX.R.LLLL.0
TRE .RSP.XX.R.LLLL.0.(B)
TRCF .RSP.XX.R.LLLL.0

e-chain overall length =
®
additional length from the
gliding feed-through LLLL +
®
the e-chain length
within the system

RSP system (without e-chain ) +
®
Pressure compensation unit +
Mounting bracket +
Gliding feed-through =
TR.RSP.XX.L or
TR.RSP.XX.R

Complete RSP pneumatic retraction
system with fi xed end on the left
and TRE trifl ex ® R series. Pressure
compensation unit, mounting
bracket and gliding feed-through
are included in the delivery. Please
order matching trifl ex ® R e-chain ®
separately.
