trifl ex R | RSE e-chains ® triflex R
®
RSE
Cable length calculation
Calculation of the e-chain total length | RSE e-chain ®
®
ø Bend radius e-chain ® length* Number of e-chains ® total length
Index R [mm] [mm] e-chains ® links [mm]
30. ▼ – – – –
40. ▼ 058 904 65 LLLL + 904
50. ▼ 080 1,044 60 LLLL + 1,044
60. ▼ – – – –
65. ▼ – – – –
65. (R 200) ▼ – – – –
70. ▼ – – – –
85. ▼ – – – –
85. (R 240) ▼ – – – –
100. ▼ – – – –
125. ▼ – – – –
*Values are related to the e-chain ® length within the system
To calculate the total e-chain ® length: please add the e-chain ® length* within the system to the LLLL standard additional length
(measured from the gliding feed-through)

e-chain ® overall length =
additional length from the gliding feed-through LLLL +
the e-chain ® length within the system

More information and installation dimensions | RSE e-chains ®
● TRC series - closed design, chip protection, smooth outer contour From page 968
● TRE series - "easy" design, very easy to fi ll, simply press cables in From page 970

3D CAD, confi gurators, service life calculation and more www.igus-asean.com/trifl exR 1033
