Economy Series
Quality Assurance Machinery Cables

Economy series YV 6WDQGDUG 7\SH
6DYLQJ
Machinery Cables 8S WR

Durability of 5 million cycles ᵔᵎ

Suitable for medium and
low speed moving parts in
equipment and 3
short-stroke cable carriers

New Launch Tough Sheath Thinner O.D. Cables / Tubes Cable Carriers /

2Product Features 2Moving Performance

2Test Conditions Carriers Cable
2Conductor
·Moving Stroke S=500mm
Stranded Conductor
TU1 Oxygen-Free Copper ·Moving Speed 1000mm/s P.183
(Copper Purity 99.99%)
·Bending Radius R=6D
Conductivity
Ductility Generic products in the market * MISUMI Economy series Cables Machinery
Composite Stranded
Conductor Cable carrier moves
Cable breaks after continuously more than
3 million cycles 5 million cycles P.190
2Sheath O.D.
Max.
High strength 25% Ordinary PVC
PVC coating Smaller material Signals Cables for
High stretch rate and little filler Low stretch rate and much filler
P.194
Small Diameter Large Outer Diameter
* Generic products in the market are similar products randomly purchased
by our company from online or offline markets
* The test data are obtained through testing by our company, which are for Tubes Heat Shrink
reference only
2Product Type
P.197
Item Non-Shielded TRVV Series Shielded TRVVP Series Shielded Twisted Pair TRVVPS Series Hubs Switching

Copper Copper Copper
Insulation Conductor Insulation Conductor Conductor P.209
Filling Filling Copper Braided
Product Paper Tape Shielding Paper Insulation
Picture Sheath Tape
Sheath
Copper
Braided Sheath
Shielding
Core Number
Range 2-20 Cores 2-6 Cores 1-20 Pairs
Cross Section
Range 0.2-2.5 mm² 0.15-0.5 mm² 0.15-0.5 mm²
Tough sheath with excellent tensile Copper wire braided shielding against More stable signal transmission
Features strength interference enabled by twisted pair technology
