Roller Transfer Mechanism

Application Industries: Automotive part
Packing
This figure shows a roller transfer
structure, which is a typical Reference price
transmission mechanism for
conveyor line type equipment.
It is commonly used in logistics
transportation equipment.

01 Cam Follower ×4 P.451 02 Aluminum Frame ×2 P.693

Urethane Coated Type Frame Standard Type
Material Urethane Shore A90 Extrusion Size 3030
Roller O.D. 40mm Total Length 1500mm

118.45 150.76

MYR/pcs MYR/pcs

03 Urethane Molded Roller ×21 P.432

Urethane Hardness Shore 90 (Green)
O.D. 40mm
I.D. 10mm
Length 100mm

85.92

MYR/pcs
