Flat Belt Transfer Mechanism

Application Industries: Packing
Electronic & Electrical
This figure shows a flat belt transfer
mechanism, which is a typical Reference price
conveyor mechanism for conveyor line
type equipment. It is commonly used in
transferring equipment of light-weight
parts such as bulk materials.

01 Flat Belt ×2 P.425 02 Linear Guide ×1 P.115

Surface Material Urethane Nominal Model 12
Belt Width 60mm Length 195mm
Circumference Length 2m
Surface Cover Green Glossy Surface

48.06 76.04

MYR/pcs MYR/pcs

03 Flat Belt Pulley·Idler ×2 P.422

Shape Straight type (Without flange)
O.D. 30mm
Shaft Dia. 8mm
Width 60mm

64.34

MYR/pcs

* All products prices are without tax. For prices reference, please visit MISUMI official website.
