Page 710 - MiSUMi FA Mechanical Components Economy Series

Tabbed Brackets For Aluminum Frames, Black

Black, Extrusion size 4040

Saving Up to 80 %
vs Standard Type
Shipping
from
1.93 MYR 1 day

20 Series 30/40 Series 45 Series
For price with different specification, please check our website
2020 3030/4040 4545
15 L W1 L W1
43 R4 8
Aluminum Frames / Related Accessories / Safety Fences H T W B A H H W1 H T W B A H H W1 42 8 19.5 R6 4 42 42 8
R
R
18.5
T1
T1
10
Aluminum Frames .Material : ADC12
4Surface Treatment : Baked Paint
How to create a
Size
model No. Extrusion L W W1 H A B R T T1 Allowable
Load (N)
P.687 6-2020 2020 17 4.5 3 20 9 3 3 2 1344
Brackets/Joints/ Sheet Metal 1.Search this keyword 8-3030 3030 28 5.8 6.4 35 12.4 10.3 3.3 4 3 1783
MISUMI WEB
tabbed bracket
Brand
P.704 2.Select Economy series 8-4040 4040 35 7.7 7.4 40 13.5 12.5 4.6 5 3.2 1935
MISUMI
Economy series
Nuts/Bolts * For more information on product specifi cations and dimensional drawings, please refer to the product catalog on the website
10-4545
2839
Refer to the 45 series dimensional drawing
4545
P.723 How to create Step Search on MISUMI official website Step Select Brand Configure Clear All
a model
Brand
Accessories/ Plate 1 Input the keyword and search on the website 2 Economy Series MISUMI
tabbed bracket
MISUMI
Economy series
P.732 Alteration
Explanation of specifi cations
Safety Fences Alteration item Add Taps on a bracket for cover mounting.
Mounting
P.743 Hole 12 &When specifying this
alteration to Extruded
Accessories for Safety Fences for Cover 12 (When size 2020, tapped hole
Alteration
M5
position is changed
from 12×12 to 8×8.
making hole)
P.750 Applicable Screws & Nuts for fi xing the brackets on
extrusions come in a set.
(Bracket+bolt+nut, added to the price of the bracket)
Applicable When specifying SET, it is equipped with steel
Screws & screws and nuts.
Nuts Set
2 T-Bolts P.727 &Cheese head screws and
2 Flange Nuts P.728 T-nuts are equipped for the
2020 specification.

707
