Workpiece Reversal Device

Application Industries: Automotive part Electronic & Electrical Packing

This figure shows a device that turns the workpiece front and back, then transfers it to the
conveyor.
It is commonly used for workpieces in the reversal section to shorten the production
interval, and is widely used in the processing and manufacturing industries of electronic
components and automobile parts.

01 Caster Swivel Type ×4 02 Bracket ×1 03 Ball Roller ×5

06 Oil Free Bushing Housing Unit×4 05 Aluminum Frame ×4 04 Leveling Mount ×4
