iglidur  Q                                                                                                                                                                                                              iglidur  Q
                                                                                                                                                                                                                                      ®
             ®
         +135°C                                                                                                                                                                                                                   +135°C
         100MPa                                                                                                                                                                                                                   100MPa
                      Bearing technology | Plain bearings | iglidur  Q                                                              Bearing technology | Plain bearings | iglidur  Q
                                                                                                                                                                                                                 ®
                                                                                                    ®
          Sleeve bearings (form S)                                                                                                  Flange bearings (form F)
                                                                                                                                                                                                   r max. 0.5
                                                                              f1  30°                                                                                                                    f1  30°



                                                                d1  0.5           d2                                                                                                      d3  d1             d2


                                                                 30°
                                                                         b1                                                                                                                  b2
                                                                                                                                                                                                   b1


                                                             2)  Thickness < 0.6mm: chamfer = 20°                                                                                      2)  Thickness < 0.6mm: chamfer = 20°
          Chamfer in relation to d1                                                                                                 Chamfer in relation to d1
          d1 [mm]   Ø 1-6     Ø 6-12   Ø 12-30    Ø > 30           Dimensions according to ISO 3547-1 and                           d1 [mm]   Ø 1-6     Ø 6-12   Ø 12-30    Ø > 30          Dimensions according to ISO 3547-1 and
          f1 [mm]    0.3       0.5        0.8       1.2            special dimensions                                               f1 [mm]    0.3       0.5       0.8       1.2            special dimensions


               Order example: QSM-0608-10 – no minimum order quantity.                                                                   Order example: QFM-0608-03 – no minimum order quantity.
               Q iglidur  material S Cylindrical M Metric 06 Inner Ø d1 08 Outer Ø d2 10 Total length b1                                 Q iglidur  material F With flange M Metric 06 Inner Ø d1 08 Outer Ø d2 03 Total length b1
                                                                                                                                                ®
                      ®
           d1        d1       d2    b1   Part No.             d1        d1       d2    b1   Part No.                                d1      d1    d2   d3    b1  b2 Part No.            d1     d1    d2    d3   b1   b2 Part No.
                  Tolerance 3)      h13                              Tolerance 3)      h13                                               Tolerance 3)  d13 3)  h13  h13                      Tolerance 3)  d13 3)  h13  h13
           [mm]              [mm]  [mm]                       [mm]              [mm]   [mm]                                         [mm]         [mm] [mm] [mm] [mm]                    [mm]         [mm] [mm] [mm] [mm]
                   +0.020                                     35.0              39.0   15.0  QSM-3539-15                            6.0           8.0  12.0  3.0 1.00 QFM-0608-03      18.0  +0.032  20.0 26.0  5.0 1.00 QFM-182026-051
           6.0               8.0   10.0  QSM-0608-10                                                                                      +0.020
                   +0.068                                     35.0              39.0   30.0  QSM-3539-30                            6.0   +0.068  8.0  12.0  4.0 1.00 QFM-0608-04      18.0  +0.102 20.0 26.0 12.0 1.00 QFM-1820-12
           8.0     +0.025    10.0   8.0  QSM-0810-08          35.0              39.0   35.0  QSM-3539-35                            6.0           8.0  12.0  8.0 1.00 QFM-0608-08      20.0          23.0 30.0 21.5 1.50 QFM-2023-21
           10.0    +0.083    12.0  10.0  QSM-1012-10          35.0              39.0   50.0  QSM-3539-50                            8.0          10.0 15.0   5.5 1.00 QFM-0810-05      25.0  +0.040   28.0 35.0 21.5 1.50 QFM-2528-21
           12.0              14.0  10.0  QSM-1214-10          40.0              44.0   30.0  QSM-4044-30                            8.0          10.0 15.0   6.0 1.00 QFM-0810-06      26.0  +0.124  29.0 35.0  5.0 1.50 QFM-2629-05
           12.0              14.0  20.0  QSM-1214-20          40.0    +0.050    44.0   40.0  QSM-4044-40                            10.0  +0.025  12.0 15.0  3.5 1.00 QFM-101215-035   27.0          30.0 38.0 20.0 1.50 QFM-2730-20
           16.0    +0.032    18.0   8.0  QSM-1618-08          40.0    +0.150    44.0   47.0  QSM-4044-47                            10.0  +0.083 12.0 18.0   6.0 1.00 QFM-1012-06      30.0          34.0 42.0 37.0 2.00 QFM-3034-37
           16.0    +0.102    18.0  12.5  QSM-1618-12          45.0              50.0   25.2  QSM-4550-252                           10.0         12.0 15.0   8.0 1.00 QFM-101215-08    35.0          39.0 47.0 26.0 2.00 QFM-3539-26
           16.0              18.0  20.0  QSM-1618-20          45.0              50.0   50.0  QSM-4550-50                            10.0         12.0 18.0 10.0 1.00 QFM-1012-10       35.0          39.0 50.0 35.0 2.00 QFM-353950-35
           18.0              20.0  20.0  QSM-1820-20          50.0              55.0   50.0  QSM-5055-50                            12.0         14.0 20.0   8.0 1.00 QFM-1214-08      40.0  +0.050  44.0 52.0 14.0 2.00 QFM-4044-14
           20.0              22.0  15.0  QSM-2022-15          50.0              55.0   60.0  QSM-5055-60                            12.0  +0.032   14.0 20.0 12.0 1.00 QFM-1214-12     40.0  +0.150 44.0 52.0 40.0 2.00 QFM-4044-40
           20.0              23.0  15.0  QSM-2023-15          50.0              55.0   80.0  QSM-5055-80                            12.0  +0.102  14.0 20.0 20.0 1.00 QFM-1214-20      50.0          55.0 63.0 10.0 2.00 QFM-5055-10
           20.0              23.0  20.0  QSM-2023-20          55.0              60.0   50.0  QSM-5560-50                            14.0         16.0 22.0 12.0 1.00 QFM-1416-12       50.0          55.0 63.0 50.0 2.00 QFM-5055-50
           20.0              23.0  25.0  QSM-2023-25          60.0              65.0   50.0  QSM-6065-50                            16.0         18.0 24.0 17.0 1.00 QFM-1618-17       60.0  +0.060  65.0 78.0 50.0 2.00 QFM-6065-50
           20.0    +0.040    23.0  30.0  QSM-2023-30          65.0    +0.060    70.0   34.0  QSM-6570-34                                                                               70.0  +0.180 75.0 83.0 50.0 2.00 QFM-7075-50
           25.0    +0.124    28.0  25.0  QSM-2528-25          70.0    +0.180    75.0   50.0  QSM-7075-50                            3)  After press-fit. Testing methods, page 61
           25.0              28.0  48.0  QSM-2528-48          75.0              80.0   40.0  QSM-7580-40
           30.0              34.0  20.0  QSM-3034-20          80.0              85.0   60.0  QSM-8085-60
           30.0              34.0  35.0  QSM-3034-35          90.0    +0.072    95.0   50.0  QSM-9095-50                                 Available from stock                               Ordering note
           30.0              34.0  40.0  QSM-3034-40                  +0.212                                                             Detailed information about delivery time online.   Our prices are scaled according to order
