iglidur PRT | Product overview
®

®
®
iglidur PRT - polymer slewing rings, standard iglidur PRT - polymer slewing rings, tooth profile
New

High torsional rigidity: Compact, lightweight With outer drive ring: With tooth profile: With inner drive ring:
and cost-effective:
Type 01 Type 04 Type 01 Type 04 Type 04
u Page 710 u Page 711 u Page 712 u Page 713 u Page 714

iglidur PRT - polymer slewing rings
®
New New New New

With angle stop: With angle stop: Manual clamp: Manual clamp: With snap mechanism: With locking device:

Type 01 Type 04 Type 01 Type 04 Type 04 Type 04
u Page 716 u Page 717 u Page 718 u Page 719 u Page 720 u Page 721

iglidur PRT - polymer slewing rings, modular system
®
New New New

Special geometries With assembled drive pin: With switching sensor: Spacer rings: Spacer rings: Black Edition: Slot nut profile: Installation solutions:
and accessories
Type 04 Type 01 i.Sense Type 01 Type 04 Type 04 Type 04 Type 04
u Page 722 u Page 724 u Page 725 u Page 726 u Page 727 u Page 728 u Page 729 u Page 730

iglidur PRT - polymer slewing rings, modular system
®
New New New New

Hygienic design: Felt cover: Position indicator: For the smallest Lightweight: Low-cost: Sliding element
applications: replacement kits:
Type 04 Type 04 Type 04 Type 04 Type 02 Type 03 Type 01 and 04
u Page 731 u Page 732 u Page 733 u Page 734 u Page 735 u Page 736 u Page 737
