iglidur
®
iglidur standards | Technical properties - quick selection standard
®
product
range

iglidur ® G G1 M250 P210 P J W300 J3 J350 X Z H1 H370 A181 A350 A500 Q2

Installation tolerances E10 E10 D11 E10 E10 E10 E10 E10 F10 F10 F10 F10 F10 E10 F10 F10 E10

Descriptive technical specifications

Wear resistance at +23°C

Wear resistance at +90°C

Wear resistance at +150°C

Slide property

Wear resistance under water

Media resistance

Resistant to edge pressures

Resistant to shock and impact loads

Dirt resistance

For high loads (> 60MPa)

Electrically conductive

Approvals and standards

Dimensions in accordance with DIN ISO 3547 ISO 3547 ISO 2795 ISO 3547 ISO 3547 ISO 3547 ISO 3547 ISO 3547 ISO 3547 ISO 3547 ISO 3547 ISO 3547 ISO 3547 ISO 3547 ISO 3547 ISO 3547 ISO 3547

FDA- and EU10/2011-compliant

Fire class in accordance with UL-94 HB HB V-2 HB HB HB HB HB V-0 V-0 V-0 V-0 V-0 HB V-0 V-1 HB

Mould test DIN EN ISO 846
Fogging DIN 75201-B

Availabilities / variants

Type S, sleeve

Type F, with flange

Type T, thrust washer
Bar stock, round bar / tube

Bar stock, plate

Machined made from bar stocks
ASEAN 09/2023 ASEAN 09/2023

70 Online tools and more information u www.igus-asean.com/iglidur 3D CAD files, prices and delivery times online u www.igus-asean.com/iglidur 71
