iglidur iglidur
®
®
®
®
tribo iglidur tribo 3D printing | Lead screw nuts iglidur tribo 3D printing | Sliding elements tribo
3D printing 3D printing
Configure lead screw nuts Configure sliding elements A
A
Round sliding element with central hole Rectangular sliding element with 2 holes
Configuration key
d5 A-A
Part type Options t
b1
A A
S
I2
d2 I1
d1 d5 A-A
t
Image exemplary Image exemplary Image exemplary S d3

Configurator Lead screw nut type Outer Ø d2 Width b1 Thread Thread direction Part type Options Part type Options
Configuration key
Configuration key
Rectangular sliding element with 2 holes
Round sliding element with central hole

Configuration limits:
Lead screw nut type S: cylindrical
Outer diameter: up to 150mm
Width: 3 to 200mm
Thread: 32 types to select from
Thread direction: R = Right hand Flat sink depth t Flat sink depth t
L = Left Configurator Glider type Inner Ø d1 Outer Ø d2 Thickness s Flat sink d5 Configurator Glider type Width b1 Length l1 Pitch l2 Thickness s Hole d3 Flat sink d5

Configuration limits: Configuration limits:
Dimensions [mm] - example configuration of cylindrical lead screw nut Glider Type 01: round with central hole Glider Type 04: Rectangle with two holes

Part No. Configuration number Outer Ø Width Thread Thread direction Inner diameter: up to 195mm Width: 10 to 200mm
d2 b1 Right left Outer diameter: up to 200mm Length: 10 to 200mm
I3-PS-02 OC-NUT-S-15.0- -TR8X1.5-R 15.0 3 - 200 TR8X1.5 ● – Height 2 : up to 100mm Flat sink: optional
I3-PS-02 OC-NUT-S-16.0- -TR10X2-L 16.0 3 - 200 TR10X2 – ● Flat sink: optional Glider type:
I3-PS-02 OC-NUT-S-18.0- -TR11X5-R 18.0 3 - 200 TR11X5 ● – 01: Round with central hole
I3-PS-02 OC-NUT-S-22.0- -TR16X2-R 22.0 3 - 200 TR16X2 ● – 02 Round with 4 holes
I3-PS-02 OC-NUT-S-26.0- -TR20X2-L 26.0 3 - 200 TR20X2 – ● 03 Round with 5 holes
I3-PS-02 OC-NUT-S-50,0- -TR30X3-R 50.0 3 - 200 TR30X3 ● – 04 Rectangle with 2 holes
05 Rectangle with 4 holes

Dimensions [mm] - example plain bearing configuration with and without flange

Part No. Configuration number Width Length Height Bore
Pitch Flat sink Flat sink
b1 l1 l2 Øs d3 d5 depth t
I3-PS-02 OC-SLIDER-04-20.0-40.0-20.0-10.0-6.4-13.0-5.0 20.0 40.0 20.0 10.0 6.4 13.0 5.0
I3-PS-02 OC-SLIDER-04-30.0-60.0-40.0-8.0-4.3-9.0-4.4 30.0 60.0 40.0 8.0 4.3 9.0 4.4
I3-PS-02 OC-SLIDER-04-50.0-100.0-60.0-11.0-8.2 50.0 100.0 60.0 11.0 8.2 – –

Configure individual trapezoidal lead screw nuts, download the STEP model and Many other glider types can be configured online: download the STEP model and
determine the price online u www.igus-asean.com/lead-screw-nut-configurator determine the price online u www.igus-asean.com/glider-configurator

Delivery time Delivery time
72hrs ASEAN 09/2023 ASEAN 09/2023 72hrs

856 Try it out now u www.igus-asean.com/cad-configurators Prices and delivery time online u www.igus-asean.com/idd 857
