Page 216 - ASEAN Chainflex Catalogue 2023

CFBUS.LB PVC iguPUR PUR TPE Basic requirements low 1 2 3 4 5 6 7 highest CFBUS.LB
TPE Travel distance unsupported 1 2 3 4 5 6 ≥ 400m TPE
7.5 x d ® Oil resistance none 1 2 3 4 highest 7.5 x d
Bus cable | TPE | chainflex CFBUS.LB Class 7.6.4.1 Torsion none 1 2 3 4 ±360°

12.5 million 7.5 x d 400m Properties and approvals Medium
UV resistance
Double strokes guaranteed Bend radius, e-chain ® Travel distance, e-chain ®

Oil resistance Oil-resistant (following DIN EN 60811-404), bio-oil-resistant (following VDMA
z For heaviest duty applications Now available 24568 with Plantocut 8 S-MB tested by DEA), Class 4
z TPE outer jacket Silicone-free Free from silicone which can affect paint adhesion (following PV 3.10.7 – status
z Shielded with UL approval 1992)
z Oil and bio-oil-resistant & 25% longer Halogen-free Following DIN EN 60754
z Low-temperature-flexible service life
z PVC and halogen-free UL verified Certificate No. B129699: "igus 36-month chainflex cable guarantee and
z Hydrolysis and microbe-resistant service life calculator based on 2 billion test cycles per year"
UL AWM See data sheet for details  www.igus-asean.com/CFBUSLB
(from production date 01/2022)
Dynamic information CLPA CFBUS.LB.045: , Reference no. 131
Bend radius e-chain linear minimum 7.5 x d CFBUS.LB.049: , Reference no. 138
®
flexible minimum 6 x d REACH In accordance with regulation (EC) No. 1907/2006 (REACH)
fixed minimum 4 x d
Temperature e-chain linear -35°C up to +70°C Lead-free Following 2011/65/EC (RoHS-II/RoHS-III)
®
flexible -50°C up to +70°C (following DIN EN 60811-504)
fixed -55°C up to +70°C (following DIN EN 50305) Cleanroom According to ISO Class 1. The outer jacket material of this series complies with
v max. unsupported 10m/s CF9.15.07 - tested by IPA according to standard DIN EN ISO 14644-1
gliding 6m/s DESINA According to VDW, DESINA standardisation
a max. 100m/s²
CE Following 2014/35/EU
Travel distance Unsupported travels and up to 400m and more for gliding applications, Class 6
UKCA In accordance with the valid regulations of the United Kingdom (as at 08/2021)
Cable structure
Conductor Stranded conductor in especially bending-resistant version consisting of bare
copper wires (following DIN EN 60228). Guaranteed service life (details see page 28-29)
Core insulation According to bus specification. Double strokes* 5 million 7.5 million 12.5 million

CFBUS.LB CFBUS.LB CFBUS.LB CFBUS.LB CFBUS.LB CFBUS.LB
Core structure According to bus specification. Temperature, .001-.022 .040-.060 .001-.022 .040-.060 .001-.022 .040-.060
from/to [°C] R min. R min. R min. R min. R min. R min.
Core identification According to bus specification. [factor x d] [factor x d] [factor x d] [factor x d] [factor x d] [factor x d]
 Product range table -35/-25 12.5 10 13.5 11 14.5 12
®
Inner jacket TPE mixture adapted to suit the requirements in e-chains . -25/+60 10 7.5 11 8.5 12 9.5
+60/+70 12.5 10 13.5 11 14.5 12
Overall shield Extremely bending-resistant braiding made of tinned copper wires. * Higher number of double strokes? Service life calculation online  www.igus-asean.com/chainflexlife
Coverage linear approx. 70%, optical approx. 90%
Outer jacket Low-adhesion, extremely abrasion-resistant and highly flexible TPE mixture, Typical application areas
adapted to suit the requirements in e-chains . z For heavy-duty applications, Class 7
®
Colour: Red lilac (similar to RAL 4001) z Unsupported travels and up to 400m and more for gliding applications, Class 6
Variants  Product range table z Almost unlimited resistance to oil, also with bio-oils, Class 4
Electrical information z No torsion, Class 1
Nominal voltage 50V z Indoor and outdoor applications without direct sun radiation
600V (following UL) z Storage and retrieval units for high-bay warehouses, machining units/machine tools,
Testing voltage 500V (following DIN EN 50289-1-3) quick handling, cleanroom, semiconductor insertion, indoor cranes, low temperature
applications
Example image

EPLAN download, configurators  www.igus-asean.com/CFBUSLB

210 36-month guarantee ... more than 1,350 cable types from stock ... no cutting charges ASEAN2023 ASEAN2023 UL-verified chainflex guarantee ... www.igus-asean.com/ul-verified 211
®
