Info ® Info
chainflex CFCLEAN …

®
... made for the e-skin flat with permanently welded cable elements
Commercially available ribbon cables
... great flexural strength thanks to special very finely stranded conductors
... protected by highly abrasion-resistant heat-sealed film
... no outer jacket, so it is small and lightweight
... for energy, bus and data
... available from stock ...

... www.igus-asean.com/cfclean

e-skin flat cable guide systems combined with
®
®
chainflex CFCLEAN cables, constitute the further
development of the conventional PTFE trackless
CFCLEAN3 DATA ELEMENTS cables for cables guides in the production environment
of displays, semiconductors and OLEDs as well as
in medical technology. The strengths of the PTFE
ribbon cable have been enhanced and the intrinsic
weaknesses eliminated. The new e-skin flat cable
®
guide system is the result of this refinement.

Stiff cable jackets prevent system bending
CFCLEAN8 BUS ELEMENTS Low restoring forces:
... due to highly flexible stranded structures
... special conductors
... no outer jacket required
CFCLEAN chainflex adapted to the application with
®
up to 21% less weight than conventional cables
About 16% smaller diameter than standard cables
with jacket
Minimum order length 1m
All standard core/cross section combinations: data,
CFCLEAN1 CONTROL ELEMENTS bus, control, motor – available from stock, with a

guarantee of up to 36 months

CFCLEAN7 MOTOR ELEMENTS
