Tools Tools
Accessories TE/INTERCONTEC | Tools and accessories TE/INTERCONTEC | Tools and accessories Accessories

Crimping tool for SERIES A and B Crimping tool for SERIES C

9
Hand crimping tool Positioning insert Hand crimping tool
for Ø 1mm contacts ² for Ø 1.0mm for Ø 3.6mm contacts ²
A up to core cross section 1mm contacts D up to core cross section 16mm Positioning insert
includes positioning insert
includes positioning carrier
for Ø 3.6mm contacts
MAT01710294 MAT01712938 MAT0179194 MAT0179195

Crimping tool for SERIES M17 Crimping tool for SERIES C

Hand crimping tool Positioning insert Pneumatic crimping tool
for Ø 0.6mm contacts for Ø 0.6mm for Ø 3.6mm and
up to core cross section 0.5mm ² contacts Ø 2.0mm contacts
B includes positioning insert Core cross section 1.5 - 16mm ²

MAT0178919 MAT0179467 MAT01721441

Crimping tool for series A, B, C, D and M17 Crimping insert for pneumatic crimping tool

1 2 3 4

C

Hand crimping tool Positioning insert Positioning insert Positioning insert Positioning insert Contact Pin Ø 2.0mm Pin Ø 3.6mm Pin Ø 3.6mm Pin Ø 3.6mm
for Ø 1mm and Ø 2mm contacts for Ø 1mm contacts for Ø 2mm contacts for Ø 1mm and Ø for Ø 2mm contacts Socket Ø 2.0mm Socket Ø 3.6mm Socket Ø 3.6mm Socket Ø 3.6mm
up to core cross section 4mm ² 2mm contacts Crimp area 1.5/2.5mm 2 4.0/6.0mm 2 10.0mm 2 16.0mm 2
includes positioning carrier

MAT0175736 MAT0178195 MAT0178196 MAT0177855 MAT01714573 MAT01727426 MAT01727428 MAT01721442 MAT01721444

Locator for pneumatic crimping tool
5 6 7 8 14

Positioning insert Positioning insert Positioning insert Positioning insert Positioning insert
for Ø 1.5mm contacts for Ø 0.5mm and Ø 2.5mm for Ø 1.6mm contacts for Ø 1.6mm contacts for Ø 1.0mm contacts
contacts Y-Tec Contact Pin Ø 2.0mm Pin Ø 3.6mm Pin Ø 3.6mm
Socket Ø 2.0mm Socket Ø 3.6mm Socket Ø 3.6mm
Crimp area 1.5/2.5mm 2 1.5 - 10.0mm 2 1.5 - 16.0mm 2
1.5/2.5mm 2
MAT01714574 MAT0178920 MAT0177853 MAT01714575 MAT01724301
MAT01727429 MAT01721443 MAT01721445

Crimping insert for series S and D
10 11 12 13
E

Battery-powered crimping tool, B131-C Crimping jaws Crimping jaws Crimping jaws Crimping jaws
2
up to 10mm , 16mm 2 up to 25mm 2 up to 35mm 2 up to 50mm 2

ASEAN2023 ASEAN2023 MAT0177854 MAT01713679 MAT01713678 MAT01713677 MAT01713676

818 EPLAN download, configurators  www.igus-asean.com/readycable 100 % digitally tested ... to your required length, no minimum order quantity ... 36-month chainflex guarantee 819
®
