chainfix strain relief | Introduction chainfix strain relief systems | Selection table

C-profile - standard and for heavy-duty applications Page

● Standard C-profile Part No. 92.42 (can be integrated into KMA) 884
● C-profile Part No. 92.52 for increased holding force (mounting in front of e-chain ) 884
®

Steel and stainless steel clamps - for maximum holding force Page
● CFX* single, double, triple clamps with standard base 888
● CFXL* single, double, triple clamps with wide base for increased holding force 889
● chainfix multi-clamps CFX12* 891
● chainfix multi-clamps CFX16* 892
chainfix tiewrap plates - universal, bolted or clip-on Page
● Option 1A: tiewrap plates as individual parts "series 2000" + cable tiewraps 894
● Option 1B: tiewrap plates as individual parts "series 3000" + cable tiewraps 895

chainfix tiewrap plates - optional variants Page

● Option 1: tiewrap plates with clip-on connection to C-profile 896
● Option 2: integrated strain relief for R series E2 e-tubes 897
● Option 3: tiewrap plates for fixed crossbars 898
● Option 4: tiewrap plates for openable crossbars 899
CFU.V - strain relief with innovative honeycomb design for fast assembly Page
● 80% faster filling (compared to CFX strain relief), openable 900
from both sides for assembly in seconds

Strain relief separators - separators with integrated strain relief teeth Page

● For easy strain relief with cable tiewraps 902

The illustration shows the new CFU honeycomb strain relief for fast
assembly. Simply insert cables and hoses into the honeycomb and close.

CFV strain relief element - stepped strain relief Page
igus chainfix strain relief. ● Relieve cable strain easily, for use outside of the e-chain section. 906
®
®
With stepped strain relief teeth, even for fully enclosed e-tubes
Flexible, secure and fast.

CFN - chainfix nuggets for C-profile and top-hat (DIN) rail 35 Page
Strain relief from igus is specifically developed for use in e-chains and dynamic applications. The combination ● Option 1: simple and universal cable fixation 907
®
®
of polymer strain relief components and chainflex cable materials offers maximum holding force and very high (for cable diameters of Ø 20mm and Ø 30mm)
®
service life for the cables. For a wide variety of applications, igus offers the best solution with respect to cost ● Option 2: fastening through clipping onto standard top-hat (DIN) rail 35 907
®
and benefits; from the CFXL strain relief for long travels in harsh environments, or the new CFU honeycomb
strain relief for fast assembly to the CFN chainfix nuggets for simple and inexpensive strain relief. igus chainfix CFB - strain relief connector system, modular and customised Page
®
strain relief components have been successfully used in thousands of applications around the world for years. ● CFB polymer strain relief connector system, for many cables in a very confined space 908

*Standard material: galvanised steel. Also available as stainless steel version (stainless steel material: 1.4301/AISI 304)
Available from stock. Ready to ship in 24 - 48hrs.*
