chainfix | Select your strain relief system Continued

e-chain CFX CFXL CFU CFN Strain relief CFV Strain relief Tiewrap plate Tiewrap plate Tiewrap plate Tiewrap plate for Tiewrap plate Tiewrap plate Tiewrap plate Tiewrap plate/ CFB strain
®
Series/system Clamp, standard Clamp, for honeycomb chainfix nugget separator Stepped can be clipped Series 2000 Series 3000 with clip-on fixed crossbars for openable for triflex ® R for E2 e-tubes teeth directly relief connector
increased strain relief strain relief onto mounting connection crossbars and triflex ® 2) moulded on the system
holding force brackets/KMA to C-profile mounting bracket
E2.1 micro
E2.10 – – – – – – – – – – – – – – X –
E2.15 – – – – – – – – – – – – – – X –
E2.1
E2.26 X 1) X 1) – – 26.Z 4) – – 2XXX.ZB – – – – – – – –
E2.38 X 1) X 1) – X – CFV.42.C – 2XXX.ZB 3XXX.ZB – C.2.522.XXX.ZS – – – – –
E2.48 X 1) X 1) X 1) X – CFV.42.C – – 3XXX.ZB – C.2.522.XXX.ZS – – – – –
E2/000
1400/1500 X 1) X 1) – – 21.1.Z – – 2XXX.ZB – – – – – – X –
1450/1480 X 1) X 1) – – 21.1.Z – – 2XXX.ZB – – – – – – X –
2400/2500 X 1) X 1) – – 2020.Z – – 2XXX.ZB – – 2050.Z – – – – –
2450/2480 X 1) X 1) – – 2020.ZR – – 2XXX.ZB – – – – – – – –
2600/2700 X X 1) – X 262.Z CFV.42.C – 2XXX.ZB 3XXX.ZB 30XX.ZC 2050.Z 2050.Z – – – Upon request
2650/2680 X X 1) – X – CFV.42.C – – 3XXX.ZB 30XX.ZC – 2050.Z 3) – – – Upon request
3400/3500 X X 1) X 1) X 301.Z CFV.42.C – – 3XXX.ZB 30XX.ZC 30XX.Z 30XX.ZS – – – Upon request
3450/3480 X X 1) X 1) X 34501.Z CFV.42.C – – 3XXX.ZB 30XX.ZC – 30XX.ZS 3) – – – Upon request
255 – – – – – – – 2XXX.ZB – – – – – – – –
E2 R100
R117/118 X 1) X 1) – – – – – 2XXX.ZB – – – – – – – –
R157/158 X 1) X 1) – – 1585.01.Z – – – – – – – – – – –
R167/168 X 1) X 1) X 1) – 1685.01.Z – – – – – – – – – – –
E2 R
R48 X 1) X 1) – – 481.ZR – – 2XXX.ZB – – – – – – – –
R58 X 1) X 1) – – – – – – – – – – – 5850.Z – –
R68 X 1) X 1) X 1) – – – – – – – – – – 30XX.Z – –
R2.1
R2.26 X 1) X 1) – – R2.26.Z CFV.R2.26.Z – – – – – – – – – –
R2.40 X 1) X 1) – – R2.40.Z CFV.R2.40.Z – – – – – – – – – –
R2.48 X 1) X 1) X 1) – – CFV.R2.48.Z – – 3XXX.ZB 30XX.ZC – – – – – –
R2.75 X 1) X 1) – – – CFV.80.C – – 3XXX.ZB 30XX.ZC – – – – – –
RX
RX32 – – – – – – X – – – – – – – – X
RX40 – – – – – – X – – – – – – – – X
RX48 – – – – – – X – – – – – – – – X
RX56 – – – – – – Upon request – – – – – – – – X

1) Assembled in front of the mounting bracket. (CFXL clamps are always assembled before the mounting bracket in a separate C-profile 92.52.XX)
2) Can be found on the product page of each e-chain ® series
3) Half e-tube only
4) For KMA mounting bracket only
= recommended strain relief for selected e-chain ®
