chainfix | Select your strain relief system Continued

e-chain CFX CFXL CFU CFN Strain relief CFV Strain relief Tiewrap plate Tiewrap plate Tiewrap plate Tiewrap plate for Tiewrap plate Tiewrap plate Tiewrap plate Tiewrap plate/ CFB strain
®
Series/system Clamp, standard Clamp, for honeycomb chainfix nugget separator Stepped can be clipped Series 2000 Series 3000 with clip-on fixed crossbars for openable for triflex ® R for E2 e-tubes teeth directly relief connector
increased strain relief strain relief onto mounting connection crossbars and triflex ® 2) moulded on the system
holding force brackets/KMA to C-profile mounting bracket
E1
E1.17.021. – – – – – – – – – – E1.021.Z – – – – –
easy chain ®
E03 – – – – – – – – – – – – – – X –
E04 – – – – – – – – – – – – – – X –
E045/Z045 – – – – – – – – – – – – – – X –
E06/Z06 – – – – – – – – – – – – – – X –
E065/Z065 – – – – – – – – – – – – – – X –
E08/Z08 – – – – – – – – – – – – – – X –
E14/Z14 – – – – – – – – – – – – – – X –
E200/Z200 X 1) – – – – – – 2XXX.ZB – – 2050.Z – – – – –
E16/Z16 – – – – – – – – – – – – – – X –
E26/Z26 X 1) – – – – – – – 3XXX.ZB – – – – – – –
E300/Z300 X 1) – – – – – – – 3XXX.ZB – – – – – – –
zipper
047 – – – – – – – – – – – – – – X –
07/R07 – – – – – – – – – – – – – – X –
09/R09 – – – – – – – – – – – – – – X –
15/R15 – – – – – – – – – – – – – – X –
17/R17 – – – – – – – – – – – – – – X –
E2 micro
03 – – – – – – – – – – – – – – X –
04 – – – – – – – – – – – – – – X –
045 – – – – – – – – – – – – – – X –
B07 – – – – – – – – – – – – – – X –
06 – – – – – – – – – – – – – – X –
074 – – – – – – – – – – – – – – X –
094 – – – – – – – – – – – – – – X –
B09 – – – – – – – – – – – – – – X –
08 – – – – – – – – – – – – – – X –
E2 mini
10 – – – – – – – – – – – – – – X –
11.031 – – – – – – – – – – – – – – X –
11.080 – – – – – – – – – – – – – – X –
11.1/11.2 – – – – – – – – – – – – – – X –
14 – – – – – – – – – – – – – – X –
B15/B15i – – – – – – – – – – – – – – X –
B17/B17i – – – – – – – – – – – – – – X –
F17 – – – – – – – – – – – – – – X –

1) Assembled in front of the mounting bracket. (CFXL clamps are always assembled before the mounting bracket in a separate C-profile 92.52.XX)
2) Can be found on the product page of each e-chain ® series
3) Half e-tube only
4) For KMA mounting bracket only
= recommended strain relief for selected e-chain ®
