chainfix | Select your strain relief system Continued

e-chain CFX CFXL CFU CFN Strain relief CFV Strain relief Tiewrap plate Tiewrap plate Tiewrap plate Tiewrap plate for Tiewrap plate Tiewrap plate Tiewrap plate Tiewrap plate/ CFB strain
®
Series/system Clamp, standard Clamp, for honeycomb chainfix nugget separator Stepped can be clipped Series 2000 Series 3000 with clip-on fixed crossbars for openable for triflex ® R for E2 e-tubes teeth directly relief connector
increased strain relief strain relief onto mounting connection crossbars and triflex ® 2) moulded on the system
holding force brackets/KMA to C-profile mounting bracket
E4.1L
E4.31L/R4.31L X 1) X 1) – – 31.Z CFV.31.N15 – – – – – – – – – –
E4.38L/R4.38L X X 1) – X 38.Z CFV.42.C – – 3XXX.ZB 30XX.ZC – C622.100.ZS – – – X
E4.48L/R4.48L X X 1) X 1) X 48.Z / 48.ZS CFV.42.C – – 3XXX.ZB 30XX.ZC – C622.100.ZS – – – X
E4.64L X X 1) – X – CFV.42.C – – 3XXX.ZB 30XX.ZC – – – – – X
E4Q
E4Q.34/E4Q.34 New X X 1) – X – CFV.42.C – – 3XXX.ZB 30XX.ZC – – – – – –
E4Q.44/E4Q.44 New X X 1) X 1) X – CFV.42.C – – 3XXX.ZB 30XX.ZC – – – – – X
E4Q.58/E4Q.58 New X X 1) – X – CFV.80.C – – 3XXX.ZB 30XX.ZC – – – – – X
E4Q.82/E4Q.82 New X X 1) – X – CFV.80.C – – 3XXX.ZB 30XX.ZC – – – – – X
E4.1
E4.21 X 1) X 1) – – T2103.Z – – 2XXX.ZB – – – – – – – –
E4.28/R4.28 X 1) X 1) – – 28.Z / 28.ZT – – 2XXX.ZB – – – 2050.Z – – – –
E4.32/H4.32/R4.32 X X 1) – X – CFV.42.C – – 3XXX.ZB 30XX.ZC – 3850.ZS – – – X
E4.42/H4.42/R4.42 X X 1) X 1) X – CFV.42.C – – 3XXX.ZB 30XX.ZC – 3850.ZS – – – X
E4.56/H4.56/R4.56 X X 1) – X – CFV.80.C – – 3XXX.ZB 30XX.ZC – 45XX.ZS – – – X
E4.80/H4.80/R4.80 X X 1) – X – CFV.80.C – – 3XXX.ZB 30XX.ZC – 45XX.ZS – – – X
E4.112 X 1) X 1) – – – – – – 3XXX.ZB – – 45XX.ZS – – – X
E4.162 X 1) X 1) – – – – – – 3XXX.ZB – – – – – – X
800 X 1) X 1) – – – – – – 3XXX.ZB – – – – – – –
840 X 1) – – – – – – – – – – – – – – –
E4/light
14040/14140/18840 X X 1) – X – – – – 3XXX.ZB 30XX.ZC – 45XX.ZS – – – X
14240/14340 X X 1) – X – – – – 3XXX.ZB 30XX.ZC – 3850.ZS – – – X
14550/14650/19050 X X 1) – X – – – – 3XXX.ZB 30XX.ZC – 45XX.ZS – – – X
15050/15150/19850 X X 1) – – – – – – 3XXX.ZB 30XX.ZC – 45XX.ZS – – – X
15250/15350 X X 1) – – – – Upon r –equest – 3XXX.ZB 30XX.ZC – 3850.ZS – – – X
1640/R1608 X X 1) – – – – Upon r –equest – 3XXX.ZB – – 45XX.ZS – – – –
YE
YE.42 New X 1) X 1) – – – – – – – – – 3850.ZS – – – –
YE.56 New X 1) X 1) – – – – – – – – – 45XX.ZS – – – –

1) Assembled in front of the mounting bracket. (CFXL clamps are always assembled before the mounting bracket in a separate C-profile 92.52.XX)
2) Can be found on the product page of each e-chain ® series
3) Half e-tube only
4) For KMA mounting bracket only
= recommended strain relief for selected e-chain ®
