Economy Series
Sprockets / Chains Product Overview

YV 6WDQGDUG 7\SH
Economy series 6DYLQJ
8S WR
Sprockets / ᵖᵎ

Chains

12 categories of Japanese Standard Type and European Standard Type
More assured with complete set purchase

Joint links can be purchased separately for high flexibility

2Customer Voice

Customer
We purchased a set of 3/8" sprockets from company A and a set of 3/8" chains from
company B, but the engineer said they could not be installed due to mismatch.
Later it was found that the chain pins were too short and the width was less than 5.7, so
the sprocket teeth failed to snap in. We had to go back to the market to find matchable
products, It was very time-consuming and labor intensive.

Customer Service

At MISUMI, you can purchase complete sets of 06B sprockets/ chains, eliminating
the mismatch problem, and you can use them directly upon arrival.

6
2MISUMI Economy series sprockets / chains with 12 categories of European
Sprockets / Chains 2European standard type (6 series)
standard type and Japanese standard type are available to meet your design needs

20B
16B
12B
06B
08B
10B
Nominal model
Sprocket Number of Teeth 10~30 10~30 10~25 11~25 11~25 9~20
Sprockets/ Chains Chain Number of links 4 and more links are customizable
P.333 2Japanese standard type (6 series)
Chains With Attachments Sprocket Number of Teeth 16~40 9~40 9~40 9~35 9~30 9~21
50
80
60
25
35
40
Nominal model
P.359 Chain Number of links 4 and more links are customizable
MISUMI Economy series sprockets and chains with the same nominal number can be used in combination.
