P. 51

1


           2EK Shaft End
                                               Fixed side shaft    Basic Rated        Screw support unit   Lead Screws / Actuators  Ball Screws /
                          Screw       Shaft overall          Number
             How to create a   Shaft  Lead  length L  end dimensions  Y  of   Load  Axial  Twisting  (Sold separately)
                model                                              C (Dynamic)  C (Static)   Play Direction
                           O.D.     (1mm increments)  E  U   Circuits                    Shape
                                                                    kN   kN
                                 05                                 6.3  20.7
              MISUMI WEB                                                                              Ball Screws
             1.Search this keyword                           4 turns,
             ball screw c7                                    1 row           0.2      Round Type
             2.Select  Economy series  32  10  300~2000  76  20  L-129  20.6  53.1  or   Right  % P.67  P.31
             Brand                                                           Less
               MISUMI
                Economy series                               1.8 turns,
                                 32                                 10.2  27.2
                                                              1 row                                  Ball Screws  Precision
           2BK Shaft End
                                                                                                     P.49
                                               Fixed side shaft    Basic Rated        Screw support unit
                          Screw       Shaft overall          Number
             How to create a   Shaft  Lead  length L  end dimensions  Y  of   Load  Axial  Twisting  (Sold separately)
                model                                              C (Dynamic)  C (Static)   Play Direction
                           O.D.     (1mm increments)  E  U   Circuits                    Shape       for Ball Screw  Support Units
                                                                    kN   kN
                                 05                                 6.3  20.7                        P.61
              MISUMI WEB
             1.Search this keyword                           4 turns,
             ball screw c7                                    1 row           0.2      Square Type
             2.Select  Economy series  32  10  300~2000  65  18  L-118  20.6  53.1  or   Right (Space-saving)  Brackets  Motor
             Brand                                                           Less        % P.65
               MISUMI
                Economy series                               1.8 turns,
                                 32                                 10.2  27.2                       P.69
                                                              1 row
           &The Y dimension must be larger than the full length of the nut            kgf=N×0.101972
             How to create                                                          Configure  Clear All  Lead Screws
               a model  Step  Search on MISUMI official website  Step   Select  Brand  Brand
                       1      ball screw c7                     2        MISUMI       MISUMI         P.71
                                                                      Economy Series
                             Input the keyword and search on the website
                                                                                       Economy series
           2Categories of use                                                              Unit: mm  Nuts  Lead Screw
                                                                     Maximum screw shaft runout tolerance
                                                Accuracy Grade
                                                                     (please see the table below for details)
                                                                                                     P.83
                 MISUMI Economy series               C7                          0.690
                 MISUMI standard product                                         0.190
           Screw shaft runout tolerance                                                              Support Units   Lead Screw
                                                              G
                                                                                                     P.86

                                  MAX20                        MAX20                                 Stop Plates  Lead Screw
                                  (Incomplete                 (Incomplete   G
                                   Hardened Area)              Hardened Area)
                                                                                                     P.90
                                               Screw shaft overall length
                    ~315   316~400  401~500  501~630  631~800  801~1000 1001~1250 1251~1600 1601~2000
            MISUMI                                                                                    Actuators
           Economy   0.110  0.130    0.160    0.190    0.230    0.300    0.380    0.500    0.690
            series
            MISUMI                                                                                   P.99
           standard   0.060  0.070   0.080    0.090    0.100    0.130    0.150    0.190      -
            product

                Alteration

           For details, please visit MISUMI offi  cial website.
