Product Overview Economy Series
Coil Springs

YV 6WDQGDUG 7\SH
Economy series 6DYLQJ Coil Springs

Tension Springs 8S WR P.545

ᵖᵎ
The same specification with 2 kinds Springs Tension

of materials
Stainless steel imported from Japan, P.555
and Chinese piano wire Tension Springs Posts For

P.561

2 Difference between MISUMI Economy series and generic products in the market Disc Springs Torsion Springs/

2 72H Salt Spray Test P.564
Generic products in the market* MISUMI Economy series Tension Springs
8H Salt Spray Test Results 72H Salt Spray Test Results Absorbers Shock

More Within P.567
than 90% 3% of
of rusted rusted 11
area area

· Conclusion: The antirust ability is 9 times of the generic products in the market. Absorbers Springs / Shock

2 Service Life Test
· Product Information: Material: SUS304-WPB
Specifications: Wire Diameter 1mm, O.D. 8mm, Free Length 40mm
· Test Conditions: Original Length 40mm, Allowable Displacement 19.2MM, Allowable Load 24.52N, Stretching Frequency 309 cycles/minute

Generic products in the market* MISUMI Economy series Tension Springs
Breakage after 255,000 cycles Breakage after 787,000 cycles

Abnormal broken position: unconventional broken coil position, Normal broken position: hook position with
presumably using low-class cheap materials with low purity concentrated stress

· Conclusion: The service life is 3 times of the generic products in the market.
* Generic products in the market are similar products randomly purchased by our company from online or offline markets
* The test data are obtained through testing by our company, which are for reference only
