iglidur P iglidur P
®
®
+130°C +130°C
50MPa 50MPa
Bearing technology | Plain bearings | iglidur P Product range
®
Flange bearings (form F) d1 d1 d2 d3 b1 b2 Part No. d1 d1 d2 d3 b1 b2 Part No.
r max. 0.5 Tolerance 3) d13 3) h13 h13 Tolerance 3) d13 3) h13 h13
f1
[mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm]
30°
30.0 +0.040 34.0 42.0 26.0 2.00 PFM-3034-26 45.0 +0.050 50.0 58.0 50.0 2.00 PFM-4550-50
30.0 34.0 42.0 30.0 2.00 PFM-3034-30 50.0 +0.150 55.0 63.0 50.0 2.00 PFM-5055-50
d3 d1 d2 +0.124
30.0 34.0 42.0 37.0 2.00 PFM-3034-37 60.0 65.0 73.0 40.0 2.00 PFM-6065-40
35.0 39.0 47.0 16.0 2.00 PFM-3539-16 60.0 +0.060 65.0 73.0 50.0 2.00 PFM-6065-50
35.0 +0.050 39.0 47.0 26.0 2.00 PFM-3539-26 70.0 +0.180 75.0 83.0 50.0 2.00 PFM-7075-50
b2
b1 40.0 +0.150 44.0 52.0 30.0 2.00 PFM-4044-30 80.0 85.0 93.0 100.0 2.50 PFM-8085-100
40.0 44.0 52.0 40.0 2.00 PFM-4044-40
2) Thickness < 0.6mm: chamfer = 20° 3) After press-fit. Testing methods, page 61
Chamfer in relation to d1
d1 [mm] Ø 1-6 Ø 6-12 Ø 12-30 Ø > 30 Dimensions according to ISO 3547-1 and
f1 [mm] 0.3 0.5 0.8 1.2 special dimensions

Order example: PFM-0405-04 – no minimum order quantity.
P iglidur material F With flange M Metric 04 Inner Ø d1 05 Outer Ø d2 04 Total length b1
®

d1 d1 d2 d3 b1 b2 Part No. d1 d1 d2 d3 b1 b2 Part No.
Tolerance 3) d13 3) h13 h13 Tolerance 3) d13 3) h13 h13
[mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm]
4.0 5.5 9.5 4.0 0.75 PFM-0405-04 14.0 16.0 22.0 8.0 1.00 PFM-1416-08
5.0 +0.020 6.0 10.0 3.0 0.50 PFM-0506-03 14.0 +0.032 16.0 22.0 12.0 1.00 PFM-1416-12
5.0 +0.068 7.0 11.0 5.0 1.00 PFM-0507-05 14.0 +0.102 16.0 22.0 17.0 1.00 PFM-1416-17
6.0 8.0 12.0 4.0 1.00 PFM-0608-04 14.0 16.0 24.0 25.0 1.00 PFM-141624-25
6.0 8.0 12.0 6.0 1.00 PFM-0608-06 14.0 +0.050 20.0 25.0 10.0 3.00 PFM-1420-10
6.0 8.0 12.0 8.0 1.00 PFM-0608-08 +0.160
7.0 9.0 15.0 4.0 1.00 PFM-0709-04 15.0 17.0 23.0 9.0 1.00 PFM-1517-09
8.0 10.0 15.0 5.5 1.00 PFM-0810-05 15.0 17.0 23.0 12.0 1.00 PFM-1517-12
8.0 +0.025 10.0 15.0 7.5 1.00 PFM-0810-07 15.0 17.0 23.0 17.0 1.00 PFM-1517-17
8.0 +0.083 10.0 15.0 9.5 1.00 PFM-0810-09 15.0 17.0 23.0 22.0 1.00 PFM-1517-22
8.0 10.0 15.0 10.0 1.00 PFM-0810-10 15.0 +0.032 18.0 24.0 32.0 1.50 PFM-151824-32
8.0 10.0 12.0 10.0 1.00 PFM-081012-10 16.0 +0.102 18.0 24.0 12.0 1.00 PFM-1618-12
8.0 10.0 15.0 15.0 1.00 PFM-0810-15 16.0 18.0 24.0 17.0 1.00 PFM-1618-17
+0.032 16.0 18.0 24.0 40.0 1.00 PFM-161824-40
10.0 12.0 18.0 5.0 1.00 PFM-1012-05
+0.102 17.0 19.0 25.0 25.0 1.00 PFM-1719-25
10.0 12.0 18.0 7.0 1.00 PFM-1012-07 18.0 20.0 26.0 12.0 1.00 PFM-1820-12
10.0 +0.025 12.0 18.0 9.0 1.00 PFM-1012-09 18.0 20.0 26.0 17.0 1.00 PFM-1820-17
10.0 +0.083 12.0 18.0 10.0 1.00 PFM-1012-10 18.0 20.0 26.0 22.0 1.00 PFM-1820-22
10.0 12.0 18.0 12.0 1.00 PFM-1012-12 20.0 23.0 30.0 11.5 1.50 PFM-2023-11 Available from stock Ordering note
10.0 12.0 18.0 17.0 1.00 PFM-1012-17 20.0 23.0 28.0 15.0 1.50 PFM-202328-15 Detailed information about delivery time online. Our prices are scaled according to order
12.0 14.0 20.0 7.0 1.00 PFM-1214-07 20.0 23.0 30.0 16.5 1.50 PFM-2023-16 www.igus-asean.com/24 quantities, current prices can be found online.
12.0 14.0 18.0 8.0 1.00 PFM-121418-08 20.0 +0.040 23.0 30.0 21.5 1.50 PFM-2023-21 Order online
12.0 14.0 20.0 9.0 1.00 PFM-1214-09 20.0 +0.124 23.0 30.0 30.0 1.50 PFM-2023-30 including delivery times, prices, online tools Discount scaling
12.0 +0.032 14.0 20.0 10.0 1.00 PFM-1214-10 24.0 27.0 32.0 22.0 1.50 PFM-2427-22 www.igus-asean.com/P 1-9 50-99 500-999
12.0 +0.102 14.0 20.0 12.0 1.00 PFM-1214-12 25.0 28.0 35.0 11.5 1.50 PFM-2528-11 10-24 100-199 1,000-2,499
12.0 14.0 20.0 15.0 1.00 PFM-1214-15 25.0 28.0 35.0 16.5 1.50 PFM-2528-16 25-49 200-499 2,500-4,999
12.0 14.0 20.0 17.0 1.00 PFM-1214-17 25.0 28.0 35.0 21.5 1.50 PFM-2528-21 No minimum order value.
14.0 16.0 22.0 4.0 1.00 PFM-1416-04 30.0 34.0 42.0 16.0 2.00 PFM-3034-16 No low-quantity surcharges.
ASEAN 09/2023 ASEAN 09/2023 above €150.
3) After press-fit. Testing methods, page 61 Free shipping within Germany for orders

142 3D-CAD, finder and service life calculation ... www.igus-asean.com/P Lubrication-free made easy ... from stock ... no minimum order quantity 143
