iglidur  P                                                                                                                                                                                                              iglidur  P
             ®
                                                                                                                                                                                                                                      ®
         +130°C                                                                                                                                                                                                                   +130°C
          50MPa                                                                                                                                                                                                                   50MPa
                      Bearing technology | Plain bearings | iglidur  P                                                              Product range
                                                                                                    ®
          Flange bearings (form F)                                                                                                  d1      d1    d2   d3    b1  b2 Part No.            d1     d1    d2    d3   b1   b2 Part No.
                                                                         r max. 0.5                                                      Tolerance 3)  d13 3)  h13  h13                      Tolerance 3)  d13 3)  h13  h13
                                                                               f1
                                                                                                                                    [mm]         [mm] [mm] [mm] [mm]                    [mm]         [mm] [mm] [mm] [mm]
                                                                                 30°
                                                                                                                                    30.0  +0.040   34.0 42.0 26.0 2.00 PFM-3034-26     45.0  +0.050  50.0 58.0 50.0 2.00 PFM-4550-50
                                                                                                                                    30.0         34.0 42.0 30.0 2.00 PFM-3034-30       50.0  +0.150 55.0 63.0 50.0 2.00 PFM-5055-50
                                                                d3  d1             d2                                                     +0.124
                                                                                                                                    30.0         34.0 42.0 37.0 2.00 PFM-3034-37       60.0          65.0 73.0 40.0 2.00 PFM-6065-40
                                                                                                                                    35.0         39.0 47.0 16.0 2.00 PFM-3539-16       60.0  +0.060  65.0 73.0 50.0 2.00 PFM-6065-50
                                                                                                                                    35.0  +0.050  39.0 47.0 26.0 2.00 PFM-3539-26      70.0  +0.180 75.0 83.0 50.0 2.00 PFM-7075-50
                                                                   b2
                                                                         b1                                                         40.0  +0.150 44.0 52.0 30.0 2.00 PFM-4044-30       80.0          85.0 93.0 100.0 2.50 PFM-8085-100
                                                                                                                                    40.0         44.0 52.0 40.0 2.00 PFM-4044-40
                                                             2)  Thickness < 0.6mm: chamfer = 20°                                   3)  After press-fit. Testing methods, page 61
          Chamfer in relation to d1
          d1 [mm]   Ø 1-6     Ø 6-12   Ø 12-30    Ø > 30           Dimensions according to ISO 3547-1 and
          f1 [mm]    0.3       0.5        0.8       1.2            special dimensions


               Order example: PFM-0405-04 – no minimum order quantity.
               P iglidur  material F With flange M Metric 04 Inner Ø d1 05 Outer Ø d2 04 Total length b1
                      ®

           d1     d1    d2    d3   b1   b2 Part No.           d1     d1    d2    d3   b1   b2 Part No.
               Tolerance 3)  d13 3)  h13  h13                      Tolerance 3)  d13 3)  h13  h13
           [mm]        [mm] [mm] [mm] [mm]                    [mm]         [mm] [mm] [mm] [mm]
          4.0           5.5  9.5   4.0 0.75 PFM-0405-04       14.0         16.0 22.0  8.0 1.00 PFM-1416-08
          5.0   +0.020   6.0  10.0  3.0 0.50 PFM-0506-03      14.0  +0.032  16.0 22.0 12.0 1.00 PFM-1416-12
          5.0   +0.068  7.0  11.0  5.0 1.00 PFM-0507-05       14.0  +0.102 16.0 22.0 17.0 1.00 PFM-1416-17
          6.0           8.0  12.0  4.0 1.00 PFM-0608-04       14.0         16.0 24.0 25.0 1.00 PFM-141624-25
          6.0           8.0  12.0  6.0 1.00 PFM-0608-06       14.0  +0.050   20.0 25.0 10.0 3.00 PFM-1420-10
          6.0           8.0  12.0  8.0 1.00 PFM-0608-08            +0.160
          7.0           9.0  15.0  4.0 1.00 PFM-0709-04       15.0         17.0 23.0  9.0 1.00 PFM-1517-09
          8.0           10.0 15.0  5.5 1.00 PFM-0810-05       15.0         17.0 23.0 12.0 1.00 PFM-1517-12
          8.0   +0.025  10.0 15.0  7.5 1.00 PFM-0810-07       15.0         17.0 23.0 17.0 1.00 PFM-1517-17
          8.0   +0.083 10.0 15.0   9.5 1.00 PFM-0810-09       15.0         17.0 23.0 22.0 1.00 PFM-1517-22
          8.0          10.0 15.0 10.0 1.00 PFM-0810-10        15.0  +0.032   18.0 24.0 32.0 1.50 PFM-151824-32
          8.0          10.0 12.0 10.0 1.00 PFM-081012-10      16.0  +0.102  18.0 24.0 12.0 1.00 PFM-1618-12
          8.0          10.0 15.0 15.0 1.00 PFM-0810-15        16.0         18.0 24.0 17.0 1.00 PFM-1618-17
                +0.032                                        16.0         18.0 24.0 40.0 1.00 PFM-161824-40
          10.0         12.0 18.0   5.0 1.00 PFM-1012-05
                +0.102                                        17.0         19.0 25.0 25.0 1.00 PFM-1719-25
          10.0         12.0 18.0   7.0 1.00 PFM-1012-07      18.0          20.0 26.0 12.0 1.00 PFM-1820-12
          10.0  +0.025   12.0 18.0  9.0 1.00 PFM-1012-09     18.0          20.0 26.0 17.0 1.00 PFM-1820-17
          10.0  +0.083  12.0 18.0 10.0 1.00 PFM-1012-10      18.0          20.0 26.0 22.0 1.00 PFM-1820-22
          10.0         12.0 18.0 12.0 1.00 PFM-1012-12       20.0          23.0 30.0 11.5 1.50 PFM-2023-11                               Available from stock                               Ordering note
          10.0         12.0 18.0 17.0 1.00 PFM-1012-17       20.0          23.0 28.0 15.0 1.50 PFM-202328-15                             Detailed information about delivery time online.   Our prices are scaled according to order
          12.0         14.0 20.0   7.0 1.00 PFM-1214-07      20.0          23.0 30.0 16.5 1.50 PFM-2023-16                               www.igus-asean.com/24                              quantities, current prices can be found online.
          12.0         14.0 18.0   8.0 1.00 PFM-121418-08    20.0  +0.040   23.0 30.0 21.5 1.50 PFM-2023-21                              Order online
          12.0         14.0 20.0   9.0 1.00 PFM-1214-09      20.0  +0.124  23.0 30.0 30.0 1.50 PFM-2023-30                               including delivery times, prices, online tools      Discount scaling
          12.0  +0.032  14.0 20.0 10.0 1.00 PFM-1214-10      24.0          27.0 32.0 22.0 1.50 PFM-2427-22                               www.igus-asean.com/P                                1-9           50-99         500-999
          12.0  +0.102 14.0 20.0 12.0 1.00 PFM-1214-12       25.0          28.0 35.0 11.5 1.50 PFM-2528-11                                                                                   10-24         100-199       1,000-2,499
          12.0         14.0 20.0 15.0 1.00 PFM-1214-15       25.0          28.0 35.0 16.5 1.50 PFM-2528-16                                                                                   25-49         200-499       2,500-4,999
          12.0         14.0 20.0 17.0 1.00 PFM-1214-17       25.0          28.0 35.0 21.5 1.50 PFM-2528-21                                                                                  No minimum order value.
          14.0         16.0 22.0   4.0 1.00 PFM-1416-04      30.0          34.0 42.0 16.0 2.00 PFM-3034-16                                                                                  No low-quantity surcharges.
                                                                                                                 ASEAN 09/2023   ASEAN 09/2023                                              above €150.
          3)  After press-fit. Testing methods, page 61                                                                                                                                     Free shipping within Germany for orders
