iglidur J350
®
+180 °C
60MPa
Bearing technology | Plain bearings | iglidur J350
®
Flange bearings (form F)
r max. 0.5 f1 30°

d3 d1 d2

b2
b1

2) Thickness < 0.6mm: chamfer = 20°
Chamfer in relation to d1
d1 [mm] Ø 1-6 Ø 6-12 Ø 12-30 Ø > 30 Dimensions according to ISO 3547-1 and
f1 [mm] 0.3 0.5 0.8 1.2 special dimensions

Order example: J350FM-0608-04 – no minimum order quantity.
J350 iglidur material F With flange M Metric 06 Inner Ø d1 08 Outer Ø d2 04 Total length b1 Ideal for plastic shafts
®
Wear-resistant at medium temperatures
d1 d1 d2 d3 b1 b2 Part No. d1 d1 d2 d3 b1 b2 Part No.
Tolerance 3) d13 3) h13 h13 Tolerance 3) d13 3) h13 h13
[mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] and loads
6.0 +0.010 8.0 12.0 4.0 1.00 J350FM-0608-04 16.0 18.0 24.0 12.0 1.00 J350FM-1618-12
6.0 +0.058 8.0 12.0 6.0 1.00 J350FM-0608-06 16.0 +0.016 18.0 24.0 17.0 1.00 J350FM-1618-17 ®
6.0 8.0 12.0 8.0 1.00 J350FM-0608-08 18.0 +0.086 20.0 26.0 12.0 1.00 J350FM-1820-12 iglidur J260
8.0 10.0 15.0 5.5 1.00 J350FM-0810-05 18.0 20.0 26.0 17.0 1.00 J350FM-1820-17
8.0 10.0 15.0 7.5 1.00 J350FM-0810-07 18.0 20.0 26.0 22.0 1.00 J350FM-1820-22
8.0 10.0 15.0 9.5 1.00 J350FM-0810-09 20.0 23.0 30.0 11.5 1.50 J350FM-2023-11
8.0 +0.013 10.0 15.0 10.0 1.00 J350FM-0810-10 20.0 23.0 30.0 16.5 1.50 J350FM-2023-16 When to use it?
10.0 +0.071 12.0 18.0 7.0 1.00 J350FM-1012-07 20.0 23.0 30.0 21.5 1.50 J350FM-2023-21 ● When polymer shafts are used
10.0 12.0 18.0 9.0 1.00 J350FM-1012-09 25.0 28.0 35.0 11.5 1.50 J350FM-2528-11 ● When the temperature rating of iglidur J is not sufficient
®
10.0 12.0 18.0 10.0 1.00 J350FM-1012-10 25.0 +0.020 28.0 35.0 16.5 1.50 J350FM-2528-16 ● When a plain bearing with low coefficient of friction is required
10.0 12.0 18.0 12.0 1.00 J350FM-1012-12 25.0 +0.104 28.0 35.0 21.5 1.50 J350FM-2528-21 ● When high wear resistance is required at medium loads
10.0 12.0 18.0 17.0 1.00 J350FM-1012-17 30.0 34.0 42.0 16.0 2.00 J350FM-3034-16 ● When good liquid media resistance is required
12.0 14.0 20.0 7.0 1.00 J350FM-1214-07 30.0 34.0 42.0 22.0 2.00 J350FM-3034-22
12.0 14.0 20.0 9.0 1.00 J350FM-1214-09 30.0 34.0 42.0 26.0 2.00 J350FM-3034-26
12.0 14.0 20.0 12.0 1.00 J350FM-1214-12 30.0 34.0 42.0 37.0 2.00 J350FM-3034-37
12.0 14.0 20.0 17.0 1.00 J350FM-1214-17 35.0 39.0 47.0 16.0 2.00 J350FM-3539-16 When not to use it?
14.0 +0.016 16.0 22.0 12.0 1.00 J350FM-1416-12 35.0 +0.025 39.0 47.0 26.0 2.00 J350FM-3539-26 ● When high surface pressures occur
+0.086
14.0 16.0 22.0 17.0 1.00 J350FM-1416-17 40.0 +0.125 44.0 52.0 30.0 2.00 J350FM-4044-30 iglidur Z
®
15.0 17.0 23.0 9.0 1.00 J350FM-1517-09 40.0 44.0 52.0 40.0 2.00 J350FM-4044-40 ● When permanent temperatures exceed +120°C
15.0 17.0 23.0 12.0 1.00 J350FM-1517-12 45.0 50.0 58.0 50.0 2.00 J350FM-4550-50 iglidur J350
®
15.0 17.0 23.0 17.0 1.00 J350FM-1517-17 ● When universal wear resistance is required
®
3) After press-fit. Testing methods, page 61 iglidur J

ASEAN 09/2023 ASEAN 09/2023

210 3D-CAD, finder and service life calculation ... www.igus-asean.com/J350
