iglidur  H5                                                                                                                                                                                                              iglidur  H5
                                                                                                                                                                                                                                     ®
             ®
         +200°C                                                                                                                                                                                                                   +200°C
          80MPa                                                                                                                                                                                                                   80MPa
                      Bearing technology | Plain bearings | iglidur  H5                                                             Technical data
                                                                                                    ®
                                                                                                                                    General properties                                                      Testing method

                                                                                                                                    Density                                            g/cm³        1.41                       -40°C up to
          Ø                                                                                                                         Colour                                                         black                       +200°C
          3.0-50.0mm
                                                                                                                                    Max. moisture absorption at +23°C/50% r.h.       % weight       0.1       DIN 53495
                                                                                                                                    Max. moisture absorption                         % weight       0.7
                                                                                                                                    Coefficient of friction, dynamic, against steel      µ       0.08-0.24                     80MPa
                                                                                                                                    pv value, max. (dry)                             MPa · m/s      0.7
          Also available
          as:                                                                                                                       Mechanical properties
                      Resistant to temperature and chemicals                                                                        Flexural modulus                                    MPa        6,400      DIN 53457
                                                                                                                                                                                                              DIN 53452
                                                                                                                                                                                                    150
                                                                                                                                                                                        MPa
                                                                                                                                    Flexural strength at +20°C
                      Robust media resistance                                                                                       Compressive strength                                MPa         n.s.
          Bar stock,                                                                                                                Max. permissible surface pressure (+20°C)           MPa         80
          round bar
          Page 743                                                                                                                  Shore D hardness                                                72        DIN 53505
                      iglidur  H5 was especially developed for the application in corrosive environments, in which high edge
                           ®
                      pressures and impact loads occur.                                                                             Physical and thermal properties
                      ● 	Good media-resistance                                                                                      Max. application temperature long-term               °C        +200                         FOOD
                      ● 	Resistant to impacts and shocks                                                                            Max. application temperature short-term              °C        +240
                      ● 	Resistant to edge pressures                                                                                Min. application temperature                         °C      up to -40
          Bar stock,                                                                                                                Thermal conductivity                              W/m · K       0.25      ASTM C 177
          plate                                                                                                                                                                        -1   -5
          Page 773    Typical application areas                                                                                     Coefficient of thermal expansion (at +23°C)       K  · 10        7        DIN 53752
                      ● 	Automotive industry                                                                                        Electrical properties
                      ● 	Automation                                                                                                 Specific transitional resistance                    Ωcm         n.s.      DIN IEC 93
                      ● 	Packaging                                                                                                  Surface resistance                                   Ω         > 10 12    DIN 53482
                                                                                                                                    Table 01: Material properties
          tribo-tape liner
          Page 781                                                                                                                  iglidur  H5 plain bearings stand for high carrying capacity,   Radiation resistance
                                                                                                                                         ®
                                                                                                                                    good abrasion resistance and good temperature      Plain bearings made from iglidur  H5 are resistant up to a
                                                                                                                                                                                                                  ®
                                                                                                                                    resistance, besides the obvious economic factors.   radiation intensity of 2 · 10² Gy.
                                                                                                                                    Temperatures up to +200°C, permitted surface pressure
                                                                                                                                    up to 65MPa, and excellent chemical resistance are only   Resistance to weathering
                                                                                                                                    some of the essential attributes. Solid lubricants reduce   iglidur   H5 plain bearings are continuously resistant
                                                                                                                                                                                            ®
          Guide rings
          Page 641                                                                                                                  the coefficient of friction and support the wear resistance,   to weathering. The material properties are only slightly
                                                                                                                                    which has been significantly improved compared to the   affected. Possible discolourations are only superficial.
                       Descriptive technical specifications                                                                         iglidur  H3 plain bearings, which are also very cost-effective.
                                                                                                                                        ®
                       Wear resistance at +23°C                     –                       +                                       iglidur   H5  plain  bearings are  suitable  for all  sliding   Mechanical properties
                                                                                                                                         ®
                                                                                                                                    surfaces.                                          With increasing temperatures, the compressive strength of
                       Wear resistance at +90°C                     –                       +
                                                                                                                                                                                       iglidur  H5 plain bearings decreases. Diagram 02 shows
                                                                                                                                                                                            ®
          Two hole     Wear resistance at +150°C                    –                       +                                       Moisture absorption                                this inverse relationship. The maximum recommended
          flange
          bearings                                                                                                                  The moisture absorption of iglidur  H5 plain bearings is   surface pressure is a mechanical material parameter. No
                                                                                                                                                                 ®
          Page 667     Slide property                               –                       +
                                                                                                                                    below 0.1% weight in ambient conditions. The saturation   conclusions regarding the tribological properties can be
                       Wear resistance under water                  –                       +                                       limit submerged in water is 0.7% weight. iglidur  H5 is   drawn from this.
                                                                                                                                                                              ®
                                                                                                                                    therefore an ideal material for wet environments.  Diagram 03 shows the elastic deformation of iglidur  H5
                                                                                                                                                                                                                                   ®
                       Media resistance                             –                       +
                                                                                                                                                                                       at radial loads.
          Moulded      Resistant to edge pressures                  –                       +                                       Vacuum                                             Surface pressure, page 45
          special parts                                                                                                             In vacuum, any present moisture is released as vapour.
          Page 696     Resistant to shock and impact loads          –                       +
                                                                                                                                    The use in vacuum is generally possible.
                       Dirt resistance                              –                       +




              ®
          igubal            Online product finder                         Online service life calculation
          spherical balls
          Page 993          www.igus-asean.com/iglidur-finder             www.igus-asean.com/iglidur-expert      ASEAN 09/2023   ASEAN 09/2023
