Page 758 - IGUS Bearing

®
®
iglidur bar iglidur round bars | Product range iglidur round bars | Product range iglidur bar
®
®
stock stock
Excellent vibration dampening - iglidur B160 The classic endurance runner up to 30MPa - iglidur W300
®
®
Order key for round bars Order key for round bars
Type Dimensions [mm] Type Dimensions [mm]
In your required In your required
length, freely length, freely
selectable between selectable between
100 and 1,000mm.
100 and 1,000mm.
Bar stock Round bar iglidur ® material Outer Ø Inner Ø Length Cut-to-size parts Bar stock Round bar iglidur ® material Outer Ø Inner Ø Length Cut-to-size parts
are delivered
are delivered
oversized.
oversized.
Dimensions [mm] Dimensions [mm]

Ø Lengths Part No. Ø Lengths Part No. Ø Lengths Part No. Ø Lengths Part No.
10 100 - 1,000 SFRM250-1000- 50 100 - 1,000 SFRB160-5000- 10 100 - 1,000 SFRW-1000- 50 100 - 1,000 SFRW-5000-
15 100 - 1,000 SFRB160-1500- 55 100 - 1,000 SFRB160-5500- 15 100 - 1,000 SFRW-1500- 55 100 - 1,000 SFRW-5500-
20 100 - 1,000 SFRB160-2000- 60 100 - 1,000 SFRB160-6000- 20 100 - 1,000 SFRW-2000- 60 100 - 1,000 SFRW-6000-
25 100 - 1,000 SFRB160-2500- 65 100 - 1,000 SFRB160-6500- 25 100 - 1,000 SFRW-2500- 65 100 - 1,000 SFRW-6500-
30 100 - 1,000 SFRB160-3000- 70 100 - 1,000 SFRB160-7000- 30 100 - 1,000 SFRW-3000- 70 100 - 1,000 SFRW-7000-
35 100 - 1,000 SFRB160-3500- 80 100 - 1,000 SFRB160-8000- 35 100 - 1,000 SFRW-3500- 80 100 - 1,000 SFRW-8000-
40 100 - 1,000 SFRB160-4000- 90 100 - 1,000 SFRB160-9000- 40 100 - 1,000 SFRW-4000- 90 100 - 1,000 SFRW-9000-
45 100 - 1,000 SFRB160-4500- 100 100 - 1,000 SFRB160-10000- 45 100 - 1,000 SFRW-4500- 100 100 - 1,000 SFRW-10000-

The versatile endurance runner - iglidur J Specialist for pivoting and pulsating loads - iglidur J3
®
®
Order key for round bars Order key for round bars

Type Dimensions [mm] Type Dimensions [mm]
In your required In your required
length, freely length, freely
selectable between selectable between
100 and 1,000mm.
100 and 1,000mm.
Bar stock Round bar iglidur ® material Outer Ø Inner Ø Length Cut-to-size parts Bar stock Round bar iglidur ® material Outer Ø Inner Ø Length Cut-to-size parts
are delivered
are delivered
oversized.
oversized.
Dimensions [mm] Dimensions [mm]

Ø Lengths Part No. Ø Lengths Part No. Ø Lengths Part No. Ø Lengths Part No.
10 100 - 1,000 SFRJ-1000- 50 100 - 1,000 SFRJ-5000- 10 100 - 1,000 SFRJ3-1000- 50 100 - 1,000 SFRJ3-5000-
15 100 - 1,000 SFRJ-1500- 55 100 - 1,000 SFRJ-5500- 15 100 - 1,000 SFRJ3-1500- 55 100 - 1,000 SFRJ3-5500-
20 100 - 1,000 SFRJ-2000- 60 100 - 1,000 SFRJ-6000- 20 100 - 1,000 SFRJ3-2000- 60 100 - 1,000 SFRJ3-6000-
25 100 - 1,000 SFRJ-2500- 65 100 - 1,000 SFRJ-6500- 25 100 - 1,000 SFRJ3-2500- 65 100 - 1,000 SFRJ3-6500-
30 100 - 1,000 SFRJ-3000- 70 100 - 1,000 SFRJ-7000- 30 100 - 1,000 SFRJ3-3000- 70 100 - 1,000 SFRJ3-7000-
35 100 - 1,000 SFRJ-3500- 80 100 - 1,000 SFRJ-8000- 35 100 - 1,000 SFRJ3-3500- 80 100 - 1,000 SFRJ3-8000-
40 100 - 1,000 SFRJ-4000- 90 100 - 1,000 SFRJ-9000- 40 100 - 1,000 SFRJ3-4000- 90 100 - 1,000 SFRJ3-9000-
45 100 - 1,000 SFRJ-4500- 100 100 - 1,000 SFRJ-10000- 45 100 - 1,000 SFRJ3-4500- 100 100 - 1,000 SFRJ3-10000-

Available from stock igus constantly expands its range of available materials and dimensions. Please contact us in case the required
®
Upon request/check availability ASEAN 09/2023 ASEAN 09/2023 diameter is not available.
756 Product finder online u www.igus-asean.com/barstock-finder Service life calculation online u www.igus-asean.com/barstock-expert 757
