Page 762 - IGUS Bearing

®
®
iglidur bar iglidur round bars | Product range iglidur round bars | Product range iglidur bar
®
®
stock stock
Ideal for pivoting movement - iglidur E7 Cost-effective and wear-resistant - iglidur RN44 New
®
®
Order key for round bars Order key for round bars
Type Dimensions [mm] Type Dimensions [mm]
In your required In your required
length, freely length, freely
selectable between selectable between
100 and 1,000mm.
100 and 1,000mm.
Bar stock Round bar iglidur ® material Outer Ø Inner Ø Length Cut-to-size parts Bar stock Round bar iglidur ® material Outer Ø Inner Ø Length Cut-to-size parts
are delivered
are delivered
oversized.
oversized.
Dimensions [mm] Dimensions [mm]

Ø Lengths Part No. Ø Lengths Part No. Ø Lengths Part No. Ø Lengths Part No.
10 100 - 1,000 SFRE7-1000- 50 100 - 1,000 SFRE7-5000- 10 100 - 1,000 SFRRN44-1000- 50 100 - 1,000 SFRRN44-5000-
15 100 - 1,000 SFRE7-1500- 55 100 - 1,000 SFRE7-5500- 15 100 - 1,000 SFRRN44-1500- 55 100 - 1,000 SFRRN44-5500-
20 100 - 1,000 SFRE7-2000- 60 100 - 1,000 SFRE7-6000- 20 100 - 1,000 SFRRN44-2000- 60 100 - 1,000 SFRRN44-6000-
25 100 - 1,000 SFRE7-2500- 65 100 - 1,000 SFRE7-6500- 25 100 - 1,000 SFRRN44-2500- 65 100 - 1,000 SFRRN44-6500-
30 100 - 1,000 SFRE7-3000- 70 100 - 1,000 SFRE7-7000- 30 100 - 1,000 SFRRN44-3000- 70 100 - 1,000 SFRRN44-7000-
35 100 - 1,000 SFRE7-3500- 80 100 - 1,000 SFRE7-8000- 35 100 - 1,000 SFRRN44-3500- 85 100 - 1,000 SFRRN44-8500-
40 100 - 1,000 SFRE7-4000- 90 100 - 1,000 SFRE7-9000- 40 100 - 1,000 SFRRN44-4000- 90 100 - 1,000 SFRRN44-9000-
45 100 - 1,000 SFRE7-4500- 100 100 - 1,000 SFRE7-10000- 45 100 - 1,000 SFRRN44-4500- 100 100 - 1,000 SFRRN44-10000-

Extremely wear-resistant in black - iglidur JB The chemical and temperature specialist - iglidur X
®
®
Order key for round bars Order key for round bars

Type Dimensions [mm] Type Dimensions [mm]
In your required In your required
length, freely length, freely
selectable between selectable between
100 and 1,000mm.
100 and 1,000mm.
Bar stock Round bar iglidur ® material Outer Ø Inner Ø Length Cut-to-size parts Bar stock Round bar iglidur ® material Outer Ø Inner Ø Length Cut-to-size parts
are delivered
are delivered
oversized.
oversized.
Dimensions [mm] Dimensions [mm]

Ø Lengths Part No. Ø Lengths Part No. Ø Lengths Part No. Ø Lengths Part No.
10 100 - 1,000 SFRJB-1000- 50 100 - 1,000 SFRJB-5000- 10 100 - 1,000 SFRX-1000- 50 100 - 1,000 SFRX-5000-
15 100 - 1,000 SFRJB-1500- 55 100 - 1,000 SFRJB-5500- 15 100 - 1,000 SFRX-1500- 55 100 - 1,000 SFRX-5500-
20 100 - 1,000 SFRJB-2000- 60 100 - 1,000 SFRJB-6000- 20 100 - 1,000 SFRX-2000- 60 100 - 1,000 SFRX-6000-
25 100 - 1,000 SFRJB-2500- 65 100 - 1,000 SFRJB-6500- 25 100 - 1,000 SFRX-2500- 65 100 - 1,000 SFRX-6500-
30 100 - 1,000 SFRJB-3000- 70 100 - 1,000 SFRJB-7000- 30 100 - 1,000 SFRX-3000- 70 100 - 1,000 SFRX-7000-
35 100 - 1,000 SFRJB-3500- 80 100 - 1,000 SFRJB-8000- 35 100 - 1,000 SFRX-3500- 80 100 - 1,000 SFRX-8000-
40 100 - 1,000 SFRJB-4000- 90 100 - 1,000 SFRJB-9000- 40 100 - 1,000 SFRX-4000- 90 100 - 1,000 SFRX-9000-
45 100 - 1,000 SFRJB-4500- 100 100 - 1,000 SFRJB-10000- 45 100 - 1,000 SFRX-4500- 100 100 - 1,000 SFRX-10000-

Available from stock igus constantly expands its range of available materials and dimensions. Please contact us in case the required
®
Upon request/check availability ASEAN 09/2023 ASEAN 09/2023 diameter is not available.
760 Product finder online u www.igus-asean.com/barstock-finder Service life calculation online u www.igus-asean.com/barstock-expert 761
