iglidur bar iglidur round bars | Product range iglidur round bars | Product range iglidur bar
®
®
stock stock
All-rounder for steam sterilisation - iglidur HSD350 Tough, wear-resistant, durable - iglidur H3 New
®
®
Order key for round bars Order key for round bars
Type Dimensions [mm] Type Dimensions [mm]
In your required In your required
length, freely length, freely
selectable selectable between
100 and 1,000mm.
between 100 and
1,000mm.
Bar stock Round bar iglidur ® material Outer Ø Inner Ø Length Cut-to-size parts Bar stock Round bar iglidur ® material Outer Ø Inner Ø Length Cut-to-size parts
are delivered
are delivered
oversized.

Dimensions [mm] oversized. Dimensions [mm]

Ø Lengths Part No. Ø Lengths Part No. Ø Lengths Part No. Ø Lengths Part No.
10 100 - 1,000 SFRHSD350-1000- 50 100 - 1,000 SFRHSD350-5000- 10 100 - 1,000 SFRH1-1000- 50 100 - 1,000 SFRH3-5000-
15 100 - 1,000 SFRHSD350-1500- 55 100 - 1,000 SFRHSD350-5500- 15 100 - 1,000 SFRH3-1500- 55 100 - 1,000 SFRH3-5500-
20 100 - 1,000 SFRHSD350-2000- 60 100 - 1,000 SFRHSD350-6000- 20 100 - 1,000 SFRH3-2000- 60 100 - 1,000 SFRH3-6000-
25 100 - 1,000 SFRHSD350-2500- 65 100 - 1,000 SFRHSD350-6500- 25 100 - 1,000 SFRH3-2500- 65 100 - 1,000 SFRH3-6500-
30 100 - 1,000 SFRHSD350-3000- 70 100 - 1,000 SFRHSD350-7000- 30 100 - 1,000 SFRH3-3000- 70 100 - 1,000 SFRH3-7000-
35 100 - 1,000 SFRHSD350-3500- 80 100 - 1,000 SFRHSD350-8000- 35 100 - 1,000 SFRH3-3500- 80 100 - 1,000 SFRH3-8000-
40 100 - 1,000 SFRHSD350-4000- 90 100 - 1,000 SFRHSD350-9000- 40 100 - 1,000 SFRH3-4000- 90 100 - 1,000 SFRH3-9000-
45 100 - 1,000 SFRHSD350-4500- 100 100 - 1,000 SFRHSD350-10000- 45 100 - 1,000 SFRH3-4500- 100 100 - 1,000 SFRH3-10000-

Endurance runner with high media resistance - iglidur H1 For extreme environmental conditions - iglidur C500
®
®
Order key for round bars Order key for round bars

Type Dimensions [mm] Type Dimensions [mm]
In your required In your required
length, freely length, freely
selectable between selectable between
100 and 1,000mm.
100 and 1,000mm.
Bar stock Round bar iglidur ® material Outer Ø Inner Ø Length Cut-to-size parts Bar stock Round bar iglidur ® material Outer Ø Inner Ø Length Cut-to-size parts
are delivered
are delivered
oversized.
oversized.
Dimensions [mm] Dimensions [mm]

Ø Lengths Part No. Ø Lengths Part No. Ø Lengths Part No. Ø Lengths Part No.
10 100 - 1,000 SFRH1-1000- 50 100 - 1,000 SFRH1-5000- 10 100 - 1,000 SFRC500-1000- 50 100 - 1,000 SFRC500-5000-
15 100 - 1,000 SFRH1-1500- 55 100 - 1,000 SFRH1-5500- 15 100 - 1,000 SFRC500-1500- 55 100 - 1,000 SFRC500-5500-
20 100 - 1,000 SFRH1-2000- 60 100 - 1,000 SFRH1-6000- 20 100 - 1,000 SFRC500-2000- 60 100 - 1,000 SFRC500-6000-
25 100 - 1,000 SFRH1-2500- 65 100 - 1,000 SFRH1-6500- 25 100 - 1,000 SFRC500-2500- 65 100 - 1,000 SFRC500-6500-
30 100 - 1,000 SFRH1-3000- 70 100 - 1,000 SFRH1-7000- 30 100 - 1,000 SFRC500-3000- 70 100 - 1,000 SFRC500-7000-
35 100 - 1,000 SFRH1-3500- 80 100 - 1,000 SFRH1-8000- 35 100 - 1,000 SFRC500-3500- 80 100 - 1,000 SFRC500-8000-
40 100 - 1,000 SFRH1-4000- 90 100 - 1,000 SFRH1-9000- 40 100 - 1,000 SFRC500-4000- 90 100 - 1,000 SFRC500-9000-
45 100 - 1,000 SFRH1-4500- 100 100 - 1,000 SFRH1-10000- 45 100 - 1,000 SFRC500-4500- 100 100 - 1,000 SFRC500-10000-

Available from stock igus constantly expands its range of available materials and dimensions. Please contact us in case the required
®
Upon request/check availability ASEAN 09/2023 ASEAN 09/2023 diameter is not available.
762 Product finder online u www.igus-asean.com/barstock-finder Service life calculation online u www.igus-asean.com/barstock-expert 763
