Page 843 - IGUS Bearing

iglidur iglidur
®
®
®
®
tribo iglidur tribofilament | Product range Notes tribo
3D printing 3D printing

Order key

tribofilament ® Diameter Weight

iglidur ® material tribofilament ® Ø [mm · 100] Spool weight [g]

iglidur J260
®

iglidur J260 - long service life
®
● Outstanding abrasion resistance of tribofilaments ®
● Application temperature from -100°C to +120°C
● For experts: high-quality processing
● Recommended printing surface:
igus adhesive film u Page 848
®

Dimensions [mm]
Filament Outer Ø Inner Ø Spool Weight Part No.
diameter spool spool width [g]
1.75 200 52 55 250 J260-PF-0175-0250
1.75 200 52 67 750 J260-PF-0175-0750
3.00 200 52 55 250 J260-PF-0300-0250
3.00 200 52 67 750 J260-PF-0300-0750

Material properties
General properties Unit iglidur ®
J260
Density g/cm 3 1.35
Colour yellow
Max. moisture absorption at +23°C and 50% r.h. % weight 0.2
Max. moisture absorption % weight 0.4
Mechanical properties
Flexural modulus MPa 1,000
Flexural strength at +20°C MPa 41/13 130)
Shore D hardness 66
Physical and thermal properties
Max. long-term application temperature °C +120
Max. short-term application temperature °C +140
Min. application temperature °C -100
Electrical properties
Specific transitional resistance Ωcm > 10 12
Surface resistance Ω > 10 10
ASEAN 09/2023 ASEAN 09/2023
130) Printed flat/upright

840 Online tools and more information u www.igus-asean.com/idd 841
