iglidur iglidur
®
®
®
®
tribo iglidur tribo 3D printing | Gear configurator iglidur tribo 3D printing | Configurators tribo
3D printing 3D printing
Wear-resistant gears in 60 seconds using the new igus gear configurator Individual rollers, lead screw nuts, sliding plates and toothed belts
®
Configure individual gears and racks in 60 Configure rollers in the desired shape
seconds, shipped within 3 days online, delivered in only 24hrs
In order to facilitate the work of designers, igus has Create and download your individual 3D model with the
®
now developed a simple and practical tool with the gear roller configurator. Then order it from the 3D printing service
configurator. This allows each customer to configure their (shipped in one to three days). Rollers with different shapes
own component even in special dimensions. In a few are possible with any dimensions between 1 and 170mm.
steps, the user only needs to enter the specifications of The rollers can be used immediately without any further
the required gear; such as the tooth module, number of machining.
teeth, width and inner diameter or select the suitable rack
profile. This automatically displays a 3D model that can
be exported as a STEP file. By uploading the file in the Delivery time
igus 3D printing service, uwww.igus-asean.com/ 3d- 24-72hrs
®
print-service the configured gear made from the new
laser sintering material iglidur i3 for gears can be ordered Configure rollers
®
immediately.With one click, the user can order their own u www.igus-asean.com/roller-configurator
wear-resistant gear with no minimum order quantity or
request a quotation. Within 3 days the custom-made gear
is ready for shipment. iglidur i3 is well suited for straight
®
and helical spur gears, racks and bevel gears.
Gear service life calculator
u www.igus-asean.com/gear-expert
Configure custom lead screw nuts, plain
bearings, sliding plates and toothed belts
in 60 seconds and they will be ready for
shipment within 3 days
In addition to individually configurable sliding plates and
plain bearings, lead screw nuts with trapezoidal threads
iglidur i6 for worm gears: double the
®
service life can be manufactured from a 3D model. Eliminating costly,
In the test, iglidur i6 showed itself to be considerably better time-consuming design and rework. Lead screw nuts,
®
than machined worm wheels. Worm wheels made of POM plain bearing and sliding plates are manufactured via laser
had total wear after 621,000 cycles, whereas worm wheels sintering.
made of iglidur i6 continued to be functional after more Lead screw nut wear test
®
than 1 million cycles. 20
®
POM POM iglidur i6
321,000 cycles 621,000 cycles 1 million cycles 12.6
Delivery time 15
High wear Failed Low wear
24-72hrs
Wear rate [mg/km] 5
Online CAD configurator for gears Online CAD configurator for plain bearings 10
u www.igus-asean.com/gear-configurator u www.igus-asean.com/3d-model 2.2 1.4 0.7 0.3

0
®
ABS iglidur iglidur iglidur iglidur
®
®
®
printed i180 J260 i3 J
printed printed printed moulded
F = 129N; l = 370mm; n = 290rpm
ASEAN 09/2023 ASEAN 09/2023 Delivery time The configurators

u www.igus-asean.com/cad-configurators
24-72hrs
850 Try it out now u www.igus-asean.com/cad-configurators Try it out now u www.igus-asean.com/cad-configurators 851
