clevis igubal clevis joints igubal clevis joints | Application examples clevis
joints joints
igubal clevis joints are all made from solid plastic igumid G to DIN 71752, which can be combined
®
®
with E series rod ends. Available components are clevis joint, clevis pin and circlip or as an alternative,
spring-loaded fixing clip.
Table
Klaus Thiesler from Bad Pyrmont, Germany is building a
table without legs that can be folded out from a kitchen
unit when needed. Thiesler is using igubal spherical
®
thrust bearings (SAM-08) for the swivel axes, iglidur
®
High tensile force When do I take them? M250 polymer plain bearings
● If high rigidity is required (M250-MFM-06) and igubal double joints (EGZM-06-25)
®
● If corrosion resistance is required for the aluminium retaining pins in the support.
Vibration-dampening ● If no lubrication is to be used
● If you want to save weight
● If maintenance-free, dry operation is required
● If simple assembly is required
● In combination with pneumatic cylinders and
gas struts

Asparagus-harvesting robot
Noise-dampening Slovenia's University of Ljubljana is developing a
When do I not take them? robotic system for automated asparagus harvesting.
● When temperatures are higher than +200°C To ensure that the vision system can operate in

Can be combined with rod ends ● When diameters above 20mm are required wet and dusty environments, the design engineers
of the dimensional series E are using iglidur polymer plain bearings (GFM-
®
0810-03) and drylin aluminium shafts (AWMP-08).
®
The components are lightweight, so the robot's
mechanical system achieves good dynamics. They
Lightweight
require no maintenance, so the system is easy for the
end user to handle.

Available from stock
Detailed information about delivery time online.

Price breaks online
No minimum order value. No minimum order quantity Rabbit puppet
Lutkovno Gledalisce Ljubljana, a Slovenian company, has
designed a cute bunny for a puppet theatre. To optimise
Max. +80°C
min. -30°C its joints' flexibility and minimise their weight, the company
uses lightweight, maintenance-free igubal angled ball
®
and socket joints.
4 types
Ø 4 - 20mm

Online product finder
