drylin N drylin N
®
®
®
®
low-profile drylin N low-profile linear guides | Product range drylin N low-profile linear guides | Product range low-profile
linear linear
guides guides
Guide rails and carriages - installation size 40 Suitable for aluminium construction profiles
C
Order key C C1
C1 C2
C2
Type Size Options

C
drylin ® N Guide carriages Type of carriage Rail width Pre-load Floating bearing in y-direction C1 C5 C5 C4 L C4 L C6 C6
C2
Complete system Standard without holes reflect A
Anti-
K A Dp K3 Dp Sp K3 Sp
Type of carriage: Floating bearing H2 H2 K
See selection aid LLY: y-direction H h y x
Options: LLZ: z-direction H h z
P: Pre-load LLYZ: yz-direction NW-01-40 NW-02-40 h1 K1
h1 a K1
C5 C4 a C6
L
Guide rail - dimensions [mm]

Part No. L a C4 C5 C6 h h1 K1 73) ly lz Weight A Dp
NW-01-40-P NW-02-40-P K3 Sp
max. min. max. [mm ] [mm ] [g/m] H2 K
4
4
NS-01-40- 72) 3,000 40 60 20 49.5 8.7 1.3 Ø4.5 26,400 970 450
NS-01-40-UNGEBOHRT- 72) 3,000 40 – – – 8.7 1.3 – 26,400 970 450 H h
NS-01-40-AR- 72) 3,000 40 60 20 49.5 8.7 1.3 Ø4.5 26,400 970 450
h1 K1
NW-11-40 NW-12-40 a
Guide carriage - dimensions [mm]

Part No. H A C C1 C2 H2 K K3 74) Sp Dp 159) Weight
73)
±0.35 [g]
NW-01-40 9.5 23.0 50 40 20 1.3 Ø4.5 – – – 30.0
NW-01-40-P 9.5 23.0 50 40 20 1.3 Ø4.5 – – – 30.0
NW-11-40 9.5 23.0 52 40 20 1.3 Ø4.5 – – – 30.0 NW-22-40
NW-02-40 9.5 23.0 50 40 20 – – M4 5.0 6.5 30.0
NW-02-40-P 9.5 23.0 50 40 20 – – M4 5.0 6.5 30.0 Selection aid - guide carriage
NW-12-40 9.5 23.0 52 40 20 – – M4 5.0 6.5 30.0 Part No. Single Double Plain hole Threaded Threaded Pre-load Solid Clipped- Overmoul-High temp.
NW-22-40 New 9.3 23.0 50 40 20 – – M4 – – 12.0
pin hole plastic on ded
72) Please give the required length in mm, symmetrical standard hole pattern C5=C6
73) For cap screw with low head (e.g. DIN 7984, DIN 6912, DIN 84, EN ISO 1707) NW-01-40 • • •
74) Metal thread NW-01-40-P • • • •
159) Hole min. Ø NW-11-40 • • •
NW-02-40 • • •
All elements can be ordered individually or as assembled systems NW-02-40-P • • • •
NS-01-40-1500: Guide rail, installation size 40, 1,500mm length NW-12-40 • • •
NW-02-40-P-LLY: Guide carriage with threaded pin, installation size 40, pre-load, floating bearing in y-direction NW-22-40 New • • •
NK-02-40-02-500-LLY: Complete system with two clipped-on guide carriages with threaded pins, installation
size 40, floating bearing in y-direction and 500mm guide rails with standard holes
