dryspin dryspin
®
®
®
lead screw dryspin | Special geometries | Product range lead screw
technology technology
Lead screw support blocks

Order key Order key

Part No. Thread Options Part No. Options

Lead screw support Fixed bearing Option left-hand thread Lead screw support Lead screw/machined end outer diameter Fixed bearing

u Page 625 block Diameter Pitch block

Options:
Scope of delivery: Anodised lead screw
support block FL: Fixed bearing
E5
tk
E2
FL: Fixed bearing with anodised clamping d1 S2 LL: Floating bearing S3 tk
ts LH: Left-hand thread option only for Tr10x2, Tr10x3, d1
ts
ring with RH thread (standard) and
kt Tr18x4, Tr24x5 kt
®
maintenance-free iglidur plain bearing 52) E3
LL: Floating bearing with lubrication-free
H E6 H
®
iglidur plain bearing
ha ha
Fixed bearing S1 Floating bearing S1 E5 E5
A tk tk d1 d1 A S2 S2 E2 E2 S3 S3 tk tk d1 d1
ts ts
ts
ts
E1 E1
kt kt kt kt
E3 E3
H H E6 E6 H H
lt lt
ha ha ha ha
S1 S1 S1
S1
A A A A
E1 E1
Technical data and dimensions [mm] - (for both right and left-hand threads) Dimensions [mm] - (for both right and left-hand threads)
E1
E1
Part No. Weight Max. static load capacity S1 S2 S3 A H E1 E2 E3 E5 E6 lt kt tk ts d1 ha
[g] axial [N]
lt lt lt lt
SLS-10X2-FL (-LH) 88 700 M8 – – 50 32 36 – – – – 30 6.5 11 6.6 10 16
SLS-10X2-LL 115 – M8 M4 M6 50 32 36 27 6.5 40 20 30 6.5 11 6.6 10 16
SLS-10X3-FL (-LH) 88 700 M8 – – 50 32 36 – – – – 30 6.5 11 6.6 10 16
SLS-10X3-LL 115 – M8 M4 M6 50 32 36 27 6.5 40 20 30 6.5 11 6.6 10 16
SLS-12X3-FL 205 1,600 M12 – – 72 46 54 – – – – 36 8.6 15 9 12 23
SLS-12X3-LL 295 – M12 M4 M6 72 46 54 27 13.5 40 20 36 8.6 15 9 12 23
SLS-14X3-FL 205 1,600 M12 – – 72 46 54 – – – – 36 8.6 15 9 14 23
SLS-14X3-LL 295 – M12 M4 M6 72 46 54 27 13.5 40 20 36 8.6 15 9 14 23
52) FL lead screw support block with trapezoidal thread TR10x2, TR10x3, TR18x4, TR24x5 lead screw also
available with clamping rings with left-hand thread
53) Can exceed max. stat. load of the lead screw nut
54) Lead screw end must be turned to d1 value
55) Lead screw end must be turned to 18mm ASEAN 09/2023 ASEAN 09/2023

484 Online tools and more information u www.igus-asean.com/lead-screw-technology 3D CAD files, prices and delivery time online u www.igus-asean.com/lead-screw-technology 485
