drylin W drylin W
®
®
®
®
profile drylin W profile guides | Product range New drylin W profile guides | Product range New profile
guides guides
Linear carriages with wear measurement, round Linear carriage with integrated manual clamp
Order key Order key
Type Size Option Type Size
Guide carriage, round Profile width [mm] Carriage length [mm] Guide carriage, round Profile width [mm] Carriage length [mm] Clamp system Kx
K2
A A2 Shaft Ø i.Sense LED display Shaft Ø
Option:
LED: With LED display Bk
C2
C
(3) Kx Kz
H2
WS-...
Technical data and dimensions [mm] Open clamp Bk Closed clamp
Part No. Weight A C A2 C2 K2 H2 57) Static load capacity
Width Length ±0.25 Coy Coz Mox Moy Moz
Kz
[kg] [N] [N] [Nm] [Nm] [Nm] Technical data and dimensions [mm]
WW-10-40-10-IS.LED New 0.3 73 100 60 87 M6 30.5 4,800 2,400 96 170 170 Part No. Min. holding Static load capacity
WW-10-40-10-IS.LED-02 New 0.3 73 100 60 87 M6 30.5 4,800 2,400 96 170 170 force Coy Coz Mox Moy Moz
WW-10-40-15-IS.LED New 0.4 73 150 60 137 M6 30.5 4,800 2,400 96 290 290 [N] [N] [N] [Nm] [Nm] [Nm]
WW-10-80-10-IS.LED New 0.4 107 100 94 87 M6 30.5 4,800 2,400 178 170 170 WW-10-40-10-HKX New 30 4,800 2,400 96 170 170
WW-16-60-15-IS.LED New 0.7 104 150 86 132 M8 39.5 8,400 4,200 240 480 480 WW-16-60-15-HKX New 60 8,400 4,200 240 480 480
WW-20-80-15-IS.LED New 1.0 134 150 116 132 M8 48.5 12,800 6,400 525 670 670 WW-20-80-15-HKX New 60 12,800 6,400 525 670 670
57) Height dimension minus the bearing clearance tolerance
Part No. Weight A C A2 C2 K2 H2 Kx Kz Bk
[kg] ±0.25
WW-10-40-10-HKX New 0.41 73 100 60 87 M6 24 45.5 104.5 25
WW-16-60-15-HKX New 0.98 104 150 86 132 M8 35 28.0 108.0 25
WW-20-80-15-HKX New 1.51 134 150 116 132 M8 44 28.0 107.0 25
Simple bearing liner replacement. Version with signal transmission, without LED.
Also available with online condition monitoring.
u www.igus-asean.com/led ASEAN 09/2023 ASEAN 09/2023
94 Online tools and more information u www.igus-asean.com/drylinW 3D CAD files, prices and delivery time online u www.igus-asean.com/drylinW 95
