Page 247 - ASEAN Chainflex Catalogue 2023

®
®
chainflex chainflex
measuring measuring
®
system Selection chart for chainflex measuring system cables system
cables cables

®
®
Drive chainflex series CF884.yyy CF211.yyy CF894.yyy CF111.yyy.D CF113.yyy.D CF11.yyy.D Drive chainflex series CF884.yyy CF211.yyy CF894.yyy CF111.yyy.D CF113.yyy.D CF11.yyy.D
technology Class 3.1.1.1 4.2.2.1 3.1.3.1 4.2.3.1 6.5.3.1 6.6.4.1 technology Class 3.1.1.1 4.2.2.1 3.1.3.1 4.2.3.1 6.5.3.1 6.6.4.1
system Jacket PVC PVC PUR PUR PUR TPE system Jacket PVC PVC PUR PUR PUR TPE
Page 242 246 252 256 262 268 Page 242 246 252 256 262 268

Number of cores and conductor Number of cores and conductor
2
nominal cross section[mm ] nominal cross section[mm ]
2
Allen Bradley LTi DRiVES
CFxxx.040.D (3x(4x0.14)+(2x0.14+2x0.34)+2x1.5)C   CFxxx.004.D (2x(2x2x0.14)+(4x0.14)C+(4x0.5))C   
B&R CFxxx.009.D (4x(2x0.25)+2x0.5)C     
CFxxx.024.D ((4x0.14)+2x(2x0.34))C   CFxxx.010.D (4x(2x0.25)+2x1.0)C  
CFxxx.027.D (5x(2x0.14)+2x0.5)C     NUM
Baumüller CFxxx.001.D (3x(2x0.14)C+(4x0.14)+(2x0.5))C    
CFxxx.027.D (5x(2x0.14)+2x0.5)C     Omron
Beckhoff CFxxx.008.D (3x(2x0.25))C  
CFxxx.007.D (4x0.34)C  CFxxx.009.D (4x(2x0.25)+2x0.5)C     
Berger Lahr CFxxx.010.D (4x(2x0.25)+2x1.0)C   
CFxxx.011.D (4x(2x0.34)+4x0.5)C      CFxxx.018.D (2x(2x0.25)+2x0.5)C   
Control Techniques Rexroth
CFxxx.001.D (3x(2x0.14)C+(4x0.14)+(2x0.5))C      CFxxx.009.D (4x(2x0.25)+2x0.5)C     
CFxxx.011.D (4x(2x0.34)+4x0.5)C      CFxxx.010.D (4x(2x0.25)+2x1.0)C   
CFxxx.026.D (6x(2x0.25)+(2x0.34)C+2x0.5)C  CFxxx.017.D (4x(2x0.14)+(4x0.14)C+4x1.0)C   
ELAU CFxxx.018.D (2x(2x0.25)+2x0.5)C   
CFxxx.009.D (4x(2x0.25)+2x0.5)C      CFxxx.019.D (3x(2x0.25)C+(3x0.25)+2x1.0)C   
Fagor Schneider Electric
CFxxx.002.D (3x(2x0.14)C+2x(0.5)C)C     CFxxx.009.D (4x(2x0.25)+2x0.5)C     
CFxxx.004.D (2x(2x2x0.14)+(4x0.14)C+(4x0.5))C    SEW
CFxxx.015.D (4x(2x0.14)+4x0.5)C      CFxxx.008.D (3x(2x0.25))C 
FANUC CFxxx.036.D (5x(2x0.25))C  
CFxxx.021.D ((4x0.25)+3x(2x0.25+2x0.5))C   CFxxx.037.D (6x(2x0.25))C  
CFxxx.022.D ((2x0.25)+5x0.5)C      Siemens
CFxxx.041.D (2x(2x0.18)+5x0.5)C   CFxxx.001.D (3x(2x0.14)C+(4x0.14)+(2x0.5))C     
CFxxx.042.D (3x(2x0.18)+6x0.5)C   CFxxx.002.D (3x(2x0.14)C+2x(0.5)C)C    
Festo CFxxx.006.D (3x(2x0.14)C+2x0.5+4x0.14+4x0.23)C     
CFxxx.002.D (3x(2x0.14)C+2x(0.5)C)C     CFxxx.011.D (4x(2x0.34)+4x0.5)C     
Heidenhain CFxxx.028.D (2x(2x0.15)+(2x0.38))C      
CFxxx.002.D (3x(2x0.14)C+2x(0.5)C)C     Stöber
CFxxx.004.D (2x(2x2x0.14)+(4x0.14)C+(4x0.5))C    CFxxx.008.D (3x(2x0.25))C  
CFxxx.005.D (4x(2x0.14)+4x0.5)C   CFxxx.009.D (4x(2x0.25)+2x0.5)C     
CFxxx.015.D (4x(2x0.14)+4x0.5)C      CFxxx.011.D (4x(2x0.34)+4x0.5)C      
CFxxx.017.D (4x(2x0.14)+(4x0.14)C+4x1.0)C    CFxxx.016.D (3x(2x0.25)C)C 
CFxxx.025.D (3x(2x0.14)C+(2x0.5)C)C   CFxxx.021.D (3x(2x0.5+2x0.25)+(4x0.25))C  
Jetter
CFxxx.025.D (3x(2x0.14)C+(2x0.5)C)C  
Lenze
CFxxx.002.D (3x(2x0.14)C+2x(0.5)C)C    
CFxxx.010.D (4x(2x0.25)+2x1.0)C   
CFxxx.025.D (3x(2x0.14)C+(2x0.5)C)C  
CFxxx.032.D 3x(2x0.14)C+(3x0.14)C   
CFxxx.033.D 4x(2x0.14)C+2x(1.0)C   
CFxxx.034.D 3x(2x0.14)C+(4x0.14)C+2x(2x0.5)C  
