Industrial Ethernet moulded, to your required length Industrial Ethernet moulded, to your required length
Number of cores and conductor Bend Number of cores and conductor Bend
Cable quality Part No. Ø Cable quality Part No. Ø
nominal cross section radius nominal cross section radius
[mm²] [mm] [x d] [mm²] [mm] [x d]

M8 cable socket/ M12 cable connector d-coded/
M8 cable connector RJ45 straight
PVC, oil-res. MAT904125450 (4x0.25)C 6.5 12.5 PVC, oil-res. MAT904125457 (4x0.25)C 6.5 12.5
PUR MAT904125410 (4x0.25)C 6.5 12.5 PUR MAT904125417 (4x0.25)C 6.5 12.5

M8 cable connector/
M8 cable connector
M12 angled connector d-coded
PVC, oil-res. MAT904125451 (4x0.25)C 6.5 12.5 RJ45 straight
PUR MAT904125411 (4x0.25)C 6.5 12.5

PVC, oil-res. MAT904125458 (4x0.25)C 6.5 12.5
M8 angled socket/ PUR MAT904125418 (4x0.25)C 6.5 12.5
open cable end
M12 cable connector d-coded/
PVC, oil-res. MAT904125452 (4x0.25)C 6.5 12.5 M8 cable connector
PUR MAT904125412 (4x0.25)C 6.5 12.5 PVC, oil-res. MAT904125459 (4x0.25)C 6.5 12.5
PUR MAT904125419 (4x0.25)C 6.5 12.5
M8 cable socket/
RJ45 straight
RJ45 straight/
PVC, oil-res. MAT904125453 (4x0.25)C 6.5 12.5 RJ45 straight
PUR MAT904125413 (4x0.25)C 6.5 12.5 PVC, oil-res. MAT904125460 (4x0.25)C 6.5 12.5

PUR MAT904125420 (4x0.25)C 6.5 12.5
M12 cable connector d-coded/
M12 cable connector d-coded
RJ45 straight/
PVC, oil-res. MAT904125454 (4x0.25)C 6.5 12.5 open cable end
PUR MAT904125414 (4x0.25)C 6.5 12.5 PVC, oil-res. MAT904125461 (4x0.25)C 6.5 12.5

PUR MAT904125421 (4x0.25)C 6.5 12.5
M12 angled connector d-coded Pin/ M12 cable socket d-coded/
open cable end M12 cable connector d-coded
PVC, oil-res. MAT904125462 (4x0.25)C 6.5 12.5
PVC, oil-res. MAT904125455 (4x0.25)C 6.5 12.5 PUR MAT904125422 (4x0.25)C 6.5 12.5
PUR MAT904125415 (4x0.25)C 6.5 12.5

M12 cable connector d-coded/ M12 cable socket d-coded/
open cable end M12 angled connector d-coded

PVC, oil-res. MAT904125456 (4x0.25)C 6.5 12.5
PUR MAT904125416 (4x0.25)C 6.5 12.5 PVC, oil-res. MAT904125463 (4x0.25)C 6.5 12.5

Special production cables  delivery time upon request PUR MAT904125423 (4x0.25)C 6.5 12.5
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core Special production cables  delivery time upon request
Harnessing RJ45 at both ends  TIA56A Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 G = with green-yellow earth core x = without earth core
Harnessing RJ45 at both ends  TIA56A
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
