Page 500 - ASEAN Chainflex Catalogue 2023

Network Network
Ethernet Ethernet
CAT6 CAT6A
Harnessed Ethernet cables | CAT6 Harnessed Ethernet cables | CAT6A

* Technical information on the cable quality: * Technical information on the cable quality:
TPE PVC, oil-res. PUR PUR-ROBOT TPE
Page 204 Page 192 Page 200 Page 410 Page 204

Harnessed Ethernet cables, CAT6, 8-pole, to your required length Harnessed Ethernet cables, CAT6A, to your required length
Cable Part No. Number of cores and conductor Ø Bend Cable Part No. Number of cores and conductor Ø Bend
quality nominal cross section radius quality nominal cross section radius
[mm²] [mm] [x d] [mm²] [mm] [x d]
Straight
Telegärtner RJ45 (CAT6A)/
Hirose RJ45 (CAT6A)/ Telegärtner RJ45 (CAT6A)
Hirose RJ45 (CAT6A)
PUR-ROBOT CAT9641001 4x(2x0.15)C 10.5 10
TPE CAT9040600 (4x(2x0.15)C)C 10.5 12.5 TPE CAT9541001 (4x(2x0.15)C)C 10.5 12.5

Metz RJ45 E-DAT IP67/ Harting RJ45 (CAT6A)/
Metz RJ45 E-DAT IP67 Harting RJ45 (CAT6A)

TPE CAT9040640 (4x(2x0.15)C)C 10.5 12.5 PUR-ROBOT CAT9641002 4x(2x0.15)C 10.5 10
TPE CAT9541002 (4x(2x0.15)C)C 10.5 12.5
Harting Han3A RJ45 (CAT6)/
Harting Han3A RJ45 (CAT6) Telegärtner RJ45 (CAT6A)/
Telegärtner RJ45 (CAT6A)
TPE CAT9040680 (4x(2x0.15)C)C 10.5 12.5
Crossover PVC, oil-res. CAT9341016 4x(2x0.20)C 10.0 12.5
PUR CAT9441016 4x(2x0.20)C 10.0 12.5
Hirose RJ45 (CAT6A)/ PUR-ROBOT CAT9641015 4x(2x0.15)C 10.5 10
Hirose RJ45 (CAT6A)
TPE CAT9541015 (4x(2x0.15)C)C 10.5 12.5
TPE CAT9040620 (4x(2x0.15)C)C 10.5 12.5
Telegärtner RJ45 (CAT6A)/
Metz RJ45 E-DAT IP67/ Telegärtner M12 x-coded
Metz RJ45 E-DAT IP67
PVC, oil-res. CAT9341017 4x(2x0.20)C 10.0 12.5
TPE CAT9040660 (4x(2x0.15)C)C 10.5 12.5 PUR CAT9441017 4x(2x0.20)C 10.0 12.5
PUR-ROBOT CAT9641016 4x(2x0.15)C 10.5 10
Harting Han3A RJ45 (CAT6)/ TPE CAT9541016 (4x(2x0.15)C)C 10.5 12.5
Harting Han3A RJ45 (CAT6)
TPE CAT9040700 (4x(2x0.15)C)C 10.5 12.5
M12 x-coded
Telegärtner RJ45 (CAT6A)/
Telegärtner M12 x-coded (CAT6A)/ Telegärtner RJ45 angled (CAT6A)
Telegärtner M12 x-coded (CAT6A)
TPE CAT9040720 (4x(2x0.15)C)C 10.5 12.5
PVC, oil-res. CAT9341018 4x(2x0.20)C 10.0 12.5
Telegärtner M12 x-coded (CAT6A)/ PUR CAT9441018 4x(2x0.20)C 10.0 12.5
open cable end
PUR-ROBOT CAT9641017 4x(2x0.15)C 10.5 10
TPE CAT9040760 (4x(2x0.15)C)C 10.5 12.5 TPE CAT9541017 (4x(2x0.15)C)C 10.5 12.5

Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core G = with green-yellow earth core x = without earth core
Harnessing RJ45 at both endsTIA56A Harnessing RJ45 at both endsTIA56A
Harnessing one end RJ45/one end M12 x-codedTIA56B Harnessing one end RJ45/one end M12 x-codedTIA56B
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
®
