igus Part No. Manufacturer Cable diameter Protection Number of Connection method Bus type Conductor Cable quality matching Maximum cable Number of cores
class contacts cross section chainflex cables diameter and conductor
®
nominal cross
mm [mm²] mm section
PVC CF888.060 7 (4x0.38)C
PVC CFBUS.PVC.040 6.5 (4x0.25)C
PVC CFBUS.PVC.060 7 (4x0.38)C
4.5-10.5 iguPUR CF898.060 7 (4x0.38)C
Series 615 TE/Intercontec (plastic clamp ring) IP67 12 Hand tool needed CAT5e/ 0.05-0.75 PUR CFBUS.PUR.040 6.5 (4x0.25)C
connector, socket 4.5-12mm Profinet PUR CFBUS.PUR.060 7 (4x0.38)C
(metal clamp ring)
TPE CFBUS.040 7 (4x0.25)C
TPE CFBUS.060 7.5 (4x0.38)C
PUR-Robot CFROBOT8.060* 8.5 (2x(2x0.34))C
PVC CF888.060 7 (4x0.38)C
PVC CFBUS.PVC.040 6.5 (4x0.25)C
PVC CFBUS.PVC.060 7 (4x0.38)C
4.5-10.5 iguPUR CF898.060 7 (4x0.38)C
(plastic clamp ring) CAT5e/
615 Coupling TE/Intercontec IP67 12 Hand tool needed 0.05-0.75 PUR CFBUS.PUR.040 6.5 (4x0.25)C
4.5-12mm Profinet PUR CFBUS.PUR.060 7 (4x0.38)C
(metal clamp ring)
TPE CFBUS.040 7 (4x0.25)C
TPE CFBUS.060 7.5 (4x0.38)C
PUR-Robot CFROBOT8.060* 8.5 (2x(2x0.34))C
PVC CFBUS.PVC.050 9.5 4x(2x0.20)C
Phoenix CAT6A/ PUR CFBUS.PUR.050 9.5 4x(2x0.20)C
MAT01733199 5.0-9.7 IP67 8 Cutting clamps 0.14-0.34
Contact Ethernet TPE CFBUS.050* 10.5 (4x(2x0.15)C)C
PUR-Robot CFROBOT8.050* 10.5 4x(2x0.15)C
PVC CF888.060 7 (4x0.38)C
PVC CFBUS.PVC.040 6.5 (4x0.25)C
PVC CFBUS.PVC.060 7 (4x0.38)C
iguPUR CF898.060 7 (4x0.38)C
Phoenix CAT6A/
MAT01733200 5.0-9.7 IP67 8 Cutting clamps 0.25-0.5 PUR CFBUS.PUR.040 6.5 (4x0.25)C
Contact Profinet
PUR CFBUS.PUR.060 7 (4x0.38)C
TPE CFBUS.040 7 (4x0.25)C
TPE CFBUS.060 7.5 (4x0.38)C
PUR-Robot CFROBOT8.060 8.5 (2x(2x0.34))C
PVC CFBUS.PVC.050 9.5 4x(2x0.20)C
Phoenix CAT6A/ PUR CFBUS.PUR.050 9.5 4x(2x0.20)C
MAT01734849 5.0-9.7 IP67 8 Cutting clamps 0.14-0.34
Contact Ethernet TPE CFBUS.050* 10.5 (4x(2x0.15)C)C
PUR-Robot CFROBOT8.050* 10.5 4x(2x0.15)C
PVC CF888.060 7 (4x0.38)C
PVC CFBUS.PVC.040 6.5 (4x0.25)C
PVC CFBUS.PVC.060 7 (4x0.38)C
iguPUR CF898.060 7 (4x0.38)C
Phoenix CAT6A/
MAT01735081 5.0-9.7 IP67 8 Cutting clamps 0.25-0.5 PUR CFBUS.PUR.040 6.5 (4x0.25)C
Contact Profinet
PUR CFBUS.PUR.060 7 (4x0.38)C
TPE CFBUS.040 7 (4x0.25)C
TPE CFBUS.060 7.5 (4x0.38)C
PUR-Robot CFROBOT8.060 8.5 (2x(2x0.34))C
PVC CF888.060 7 (4x0.38)C
PVC CFBUS.PVC.040 6.5 (4x0.25)C
PVC CFBUS.PVC.060 7 (4x0.38)C
CAT5/ iguPUR CF898.060 7 (4x0.38)C
MAT01716619 Siemens 6.5-6.5 IP20 4 Cutting clamps 0.14-0.38
Profinet PUR CFBUS.PUR.040 6.5 (4x0.25)C
PUR CFBUS.PUR.060 7 (4x0.38)C
TPE CFBUS.040 7 (4x0.25)C
TPE CFBUS.060* 7.5 (4x0.38)C
PVC CFBUS.PVC.049 7.5 (4x(2x0.15))C
PUR CFBUS.PUR.049 7.5 (4x(2x0.15))C
MAT01721074 Siemens 8.0-8.0 IP20 8 Cutting clamps CAT6 0.14-0.25
TPE CFBUS.049* 8.5 (4x(2x0.15))C
PUR-Robot CFROBOT8.049* 8.5 4x(2x0.14)C
All connectors are downward compatible. Please note the outer diameter of the cable and the conductor cross section. * According to data sheet, the connectors do not match these cables but the cables can nevertheless be manually modified/tapered.
