Page 529 - ASEAN Chainflex Catalogue 2023

FOC FOC
Network Network
Glass fibre Glass fibre
Harnessed Fibre Optic Cables for network | TPE Harnessed Fibre Optic Cables for network | TPE

* Technical information on the cable quality: * Technical information on the cable quality:
TPE TPE
From page 228 From page 228

Harnessed Fibre Optic Cables, glass-fibre, 6/12 fibres, to your required length Harnessed Fibre Optic Cables, glass-fibre, 6/12 fibres, to your required length
Cable Part No. No. of fibres Fibre Ø Bend Cable Part No. No. of fibres Fibre Ø Bend
quality diameter radius quality diameter radius
[mm] [x d] [mm] [x d]

ST/ST Connector ST/ST Connector

Pre-harnessed at both ends Pre-harnessed at both ends
TPE H* LWL9040091 6 50/125 11.0 5 LWL9040030 6 50/125 10.0 10
TPE H* LWL9040090 6 62.5/125 11.0 5 LWL9040045 6 62.5/125 10.0 10
TPE H* LWL90428938 12 50/125 14.0 5 incl. conversion to SC LWL9040032 6 50/125 10.0 10
TPE H* LWL90428937 12 62.5/125 14.0 5 incl. conversion to SC LWL9040047 6 62.5/125 10.0 10
incl. conversion to LC LWL9040031 6 50/125 10.0 10
LC/LC Connector incl. conversion to LC LWL9040046 6 62.5/125 10.0 10

Pre-harnessed at both ends
TPE H* LWL90428946 6 50/125 11.0 5 ST/ST Connector
TPE H* LWL90428945 6 62.5/125 11.0 5
TPE H* LWL90428942 12 50/125 14.0 5
TPE H* LWL90428941 12 62.5/125 14.0 5 Pre-harnessed at both ends
LWL9040060 12 50/125 10.0 10
SC/SC Connector LWL9040075 12 62.5/125 10.0 10
incl. conversion to SC LWL9040062 12 50/125 10.0 10
Pre-harnessed at both ends incl. conversion to SC LWL9040077 12 62.5/125 10.0 10
TPE H* LWL90428944 6 50/125 11.0 5 incl. conversion to LC LWL9040061 12 50/125 10.0 10
TPE H* LWL90428943 6 62.5/125 11.0 5 incl. conversion to LC LWL9040076 12 62.5/125 10.0 10
TPE H* LWL90428940 12 50/125 14.0 5
TPE H* LWL90428939 12 62.5/125 14.0 5 Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core

Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example images. Harnessed with these connectors
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
®
Connec-
tor ST
Harnessed with these connectors
Tube sinking
Connec- SC ST LC
tor
Tube sinking
Tube sinking
LWL90428936 Closed corrugated tube to feed in Fibre Optic Cables
Tube sinking (shown cut open)

LWL90428935 Closed corrugated tube to feed in Fibre Optic Cables Fibre identification
(shown cut open) Part No. Fibre identification Hollow core
identification
CFLG.6G.62,5/125.TC ecru, yellow, green, red, violet, blue orange
CFLG.6G.50/125.TC ecru, yellow, green, red, violet, blue blue
CFLG.12G.62,5/125.TC ecru, yellow, green, red, violet, blue, light blue, orange
grey, brown, black, orange, pink
ASEAN2023 ASEAN2023 CFLG.12G.50/125.TC ecru, yellow, green, red, violet, blue, light blue, blue
grey, brown, black, orange, pink
522 EPLAN download, configurators  www.igus-asean.com/network 523
