Harnessed control cables | HARTING Han 10B

Harnessed control cables, Harting Han 10B, to your required length
Insert 1 Housing 1 Insert 2 Housing 2
Cable Part No. Number of cores and conductor Ø Copper Weight Bend chainflex HARTING HARTING HARTING HARTING
®
quality nominal cross section index radius cable
Part No. Part No. Part No. Part No.
[mm²] [mm] [x d]

Han 10B connector housing (pin) to Han 10B connector housing (socket),
single locking lever at both ends, straight

PVC MAT90489376 12G1.5 12.0 186 260 12.5 CF880.15.12 09330102702 19300101441 09330102602 19300101441
PVC MAT90489377 12G1.5 13.0 179 288 7.5 CF130.15.12.UL 09330102702 19300101441 09330102602 19300101441
PVC, oil-res. MAT90489378 12G1.5 13.0 179 288 7.5 CF130.15.12.UL 09330102702 19300101441 09330102602 19300101441
iguPUR MAT90489379 12G1.5 12.0 186 256 12.5 CF890.15.12 09330102702 19300101441 09330102602 19300101441
PUR MAT90489380 12G1.5 13.0 179 297 6.8 CF77.UL.15.12.D 09330102702 19300101441 09330102602 19300101441
PUR-ROBOT MAT90489383 16G1.0+(2x1.0)C 15.5 194 307 10 CFROBOT9.004 09330102702 19300101441 09330102602 19300101441
TPE H* MAT90489381 12G1.5 13.0 179 284 5 CF9.15.12 09330102702 19300101441 09330102602 19300101441
TPE F MAT90489382 12G1.5 13.5 178 307 5 CF9.UL.15.12 09330102702 19300101441 09330102602 19300101441

Han 10B connector housing (pin) to Han 10B connector housing (socket),
single locking lever at both ends, angled
PVC MAT90489384 12G1.5 12.0 186 260 12.5 CF880.15.12 09330102702 19300101541 09330102602 19300101541
PVC MAT90489385 12G1.5 13.0 179 288 7.5 CF130.15.12.UL 09330102702 19300101541 09330102602 19300101541
PVC, oil-res. MAT90489386 12G0.5 11.0 61 131 6.8 CF130.15.12.UL 09330102702 19300101541 09330102602 19300101541
iguPUR MAT90489387 12G1.5 12.0 186 256 12.5 CF890.15.12 09330102702 19300101541 09330102602 19300101541
PUR MAT90489388 12G1.5 13.0 179 297 6.8 CF77.UL.15.12.D 09330102702 19300101541 09330102602 19300101541
PUR-ROBOT MAT90489391 16G1.0+(2x1.0)C 15.5 194 307 10 CFROBOT9.004 09330102702 19300101541 09330102602 19300101541
TPE H* MAT90489389 12G1.5 13.0 179 284 5 CF9.15.12 09330102702 19300101541 09330102602 19300101541
TPE F MAT90489390 12G1.5 13.5 178 307 5 CF9.UL.15.12 09330102702 19300101541 09330102602 19300101541

Han 10B connector housing (pin) to Han 10B connector housing (socket),
double locking lever at both ends, straight

PVC MAT90489392 12G1.5 12.0 186 260 12.5 CF880.15.12 09330102702 19300101421 09330102602 19300101421
PVC MAT90489393 12G1.5 13.0 179 288 7.5 CF130.15.12.UL 09330102702 19300101421 09330102602 19300101421
PVC, oil-res. MAT90489394 12G1.5 15.0 179 264 6.8 CF130.15.12.UL 09330102702 19300101421 09330102602 19300101421
iguPUR MAT90489395 12G1.5 12.0 186 256 12.5 CF890.15.12 09330102702 19300101421 09330102602 19300101421
PUR MAT90489396 12G1.5 13.0 179 297 6.8 CF77.UL.15.12.D 09330102702 19300101421 09330102602 19300101421
PUR-ROBOT MAT90489399 16G1.0+(2x1.0)C 15.5 194 307 10 CFROBOT9.004 09330102702 19300101421 09330102602 19300101421
TPE H* MAT90489397 12G1.5 13.0 179 284 5 CF9.15.12 09330102702 19300101421 09330102602 19300101421
TPE F MAT90489398 12G1.5 13.5 178 307 5 CF9.UL.15.12 09330102702 19300101421 09330102602 19300101421

Han 10B connector housing (pin) to Han 10B connector housing (socket),
double locking lever at both ends, angled
PVC MAT90489400 12G1.5 12.0 186 260 12.5 CF880.15.12 09330102702 19300101521 09330102602 19300101521
PVC MAT90489401 12G1.5 13.0 179 288 7.5 CF130.15.12.UL 09330102702 19300101521 09330102602 19300101521
PVC, oil-res. MAT90489402 12G1.5 15.0 179 264 6.8 CF130.15.12.UL 09330102702 19300101521 09330102602 19300101521
iguPUR MAT90489403 12G1.5 12.0 186 256 12.5 CF890.15.12 09330102702 19300101521 09330102602 19300101521
PUR MAT90489404 12G1.5 13.0 179 297 6.8 CF77.UL.15.12.D 09330102702 19300101521 09330102602 19300101521
PUR-ROBOT MAT90489407 16G1.0+(2x1.0)C 15.5 194 307 10 CFROBOT9.004 09330102702 19300101521 09330102602 19300101521
TPE H* MAT90489405 12G1.5 13.0 179 284 5 CF9.15.12 09330102702 19300101521 09330102602 19300101521
TPE F MAT90489406 12G1.5 13.5 178 307 5 CF9.UL.15.12 09330102702 19300101521 09330102602 19300101521
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 ASEAN2023 ASEAN2023
