Robot Robot
KUKA Harnessed cables for robots Direct connection cables for robots KUKA
Titan Titan
KUKA Titan KUKA Titan

Harnessed cables for KUKA Titan, to your required length Direct connection cables for KUKA Titan, to your required length
®
®
chainflex Manufacturer Number of cores and conductor chainflex Number of cores and conductor
Part No. Ø Part No. Ø
cable description nominal cross section cable nominal cross section
[mm²] [mm] [mm²] [mm]

Motor cable
Motor cable (direct connection cable)
(angled socket)

MAT904141228 CFSPECIAL.792.014 (2x(3x1.5)C+3x(3x10)+1G10)C 35.5
MAT904105011 CFSPECIAL.792.014 X30.1/X30.1.1 (2x(3x1.5)C+3x(3x10)+1G10)C 35.5 MAT904141230 CFSPECIAL.792.014 (2x(3x1.5)C+3x(3x10)+1G10)C 35.5
MAT904105014 CFSPECIAL.792.014 X30.2/X30.2.1 (2x(3x1.5)C+3x(3x10)+1G10)C 35.5 MAT904141231 CFSPECIAL.792.014 (2x(3x1.5)C+3x(3x10)+1G10)C 35.5
MAT904105015 CFSPECIAL.792.014 X30.3/X30.3.1 (2x(3x1.5)C+3x(3x10)+1G10)C 35.5
Signal cable
(direct connection cable)
Data cable
MAT904141227 CFBUS.PUR.H01.060 ((4x0.38)C+4x1.5)C 11.5
MAT904105005 CFBUS.PUR.H01.060 X31/X31.1 ((4x0.38)C+4x1.5)C 11.5 Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
®
Motor cable
single axis (axis 7)

MAT904105006 CF270.UL.25.15.02.01.D XM.../X... (4G2.5+(2x1.5)C)C 14.0
MAT904105007 CF270.UL.40.15.02.01.D XM.../X... (4G4.0+(2x1.5)C)C 15.0

Motor cable
single axis (axis 7)

MAT904105008 CF270.UL.60.15.02.01.D XM.../X... (4G6.0+(2x1.5)C)C 16.5

Control cable
(axis 7)

Control cable
MAT904105013 CF112.02.04.02 (4x(2x0.25)C)C 11.0
single axis

Earth-core

Connector
MAT904105010 CFPE.160.01 1G16 9.5
plate/robot
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits.
G = with green-yellow earth core x = without earth core
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
