Harnessed drive cables | Bosch Rexroth Harnessed drive cables | Bosch Rexroth
Bosch Bosch
Rexroth Rexroth
PVC/PUR/TPE EPLAN macros available online Page 582/583 PVC/PUR/TPE EPLAN macros available online Page 582/583
* Technical information on the cable quality (Code 01-31): Page 578-581 * Technical information on the cable quality (Code 01-31): Page 578-581
Cable quality Part No. Number of cores and conductor Ø R min. Cable quality Part No. Number of cores and conductor Ø R min.
nominal cross section nominal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
Bosch Rexroth Encoder cables Bosch Rexroth Encoder cables
Basic cable Basic cable
IKS4001 IKS4142
PVC 08 MAT9110026 (4x(2x0.14)+(4x0.14)C+4x1.0)C 10.0 10 PVC 08 MAT9110007 (4x(2x0.14)+(4x0.14)C+4x1.0)C 10.0 10
PUR M.I. 10 MAT9841311 (4x(2x0.14)+(4x0.14)C+4x1.0)C 10.0 7.5 PUR M.I. 10 MAT9841319 (4x(2x0.14)+(4x0.14)C+4x1.0)C 10.0 7.5
TPE H* 11 MAT9100026 (4x(2x0.14)+(4x0.14)C+4x1.0)C 10.0 6.8 TPE H* 11 MAT9100007 (4x(2x0.14)+(4x0.14)C+4x1.0)C 10.0 6.8
IKS4002 IKS4314
PVC 08 MAT9110010 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 10 PVC 08 MAT9110004 (4x(2x0.25)+2x1.0)C 8.5 10
PUR M.I. 10 MAT9841312 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 7.5 PUR M.I. 10 MAT9841320 (4x(2x0.25)+2x1.0)C 9.0 7.5
TPE H* 11 MAT9100010 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 6.8 TPE H* 11 MAT9100004 (4x(2x0.25)+2x1.0)C 9.0 6.8
IKS4020 IKS4374
PVC 08 MAT9110006 (4x(2x0.14)+(4x0.14)C+4x1.0)C 10.0 10 PVC 08 MAT9110002 (4x(2x0.25)+2x0.5)C 8.0 10
PUR M.I. 10 MAT9841313 (4x(2x0.14)+(4x0.14)C+4x1.0)C 10.0 7.5 PUR M.I. 10 MAT9841321 (4x(2x0.25)+2x0.5)C 8.5 7.5
TPE H* 11 MAT9100006 (4x(2x0.14)+(4x0.14)C+4x1.0)C 10.0 6.8 TPE H* 11 MAT9100002 (4x(2x0.25)+2x0.5)C 8.5 6.8
IKS4038 IKS4375
PVC 08 MAT9110027 (4x(2x0.14)+(4x0.14)C+4x1.0)C 10.0 10 PVC 08 MAT9110003 (4x(2x0.25)+2x0.5)C 8.0 10
PUR M.I. 10 MAT9841314 (4x(2x0.14)+(4x0.14)C+4x1.0)C 10.0 7.5 PUR M.I. 10 MAT9841322 (4x(2x0.25)+2x0.5)C 8.5 7.5
TPE H* 11 MAT9100027 (4x(2x0.14)+(4x0.14)C+4x1.0)C 10.0 6.8 TPE H* 11 MAT9100003 (4x(2x0.25)+2x0.5)C 8.5 6.8
IKS4041 IKS4384
PVC 08 MAT9110028 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 10 PVC 08 MAT9110005 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 10
PUR M.I. 10 MAT9841315 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 7.5 PUR M.I. 10 MAT9841323 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 7.5
TPE H* 11 MAT9100028 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 6.8 TPE H* 11 MAT9100005 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 6.8
IKS4042 IKS4389
PVC 08 MAT9110017 (4x(2x0.25)+2x0.5)C 8.0 10 PVC 08 MAT9110033 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 10
PUR M.I. 10 MAT9841316 (4x(2x0.25)+2x0.5)C 8.5 7.5 PUR M.I. 10 MAT9841324 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 7.5
TPE H* 11 MAT9100017 (4x(2x0.25)+2x0.5)C 8.5 6.8 TPE H* 11 MAT9100033 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 6.8
Basic cable Basic cable
IKS4066 RG2-002AAB-NN-xxx,x
PVC 08 MAT9110025 (4x(2x0.25)+2x0.5)C 8.0 10 PVC 08 MAT9741301 (2x(2x0.25)+2x0.5)C 6.5 10
PUR M.I. 10 MAT9841317 (4x(2x0.25)+2x0.5)C 8.5 7.5 TPE H* 11 MAT9941301 (2x(2x0.25)+2x0.5)C 6.5 6.8
TPE H* 11 MAT9100025 (4x(2x0.25)+2x0.5)C 8.5 6.8 RKG0014
PVC 08 MAT9110030 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 10
PUR M.I. 10 MAT9841301 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 7.5
Basic cable
TPE H* 11 MAT9100030 (3x(2x0.25)C+(3x0.25)+2x1.0)C 10.0 6.8
RKG0020
IKS4103 PVC 08 MAT9110034 (4x(2x0.25)+2x0.5)C 8.0 10
PVC 08 MAT9110001 (4x(2x0.25)+2x0.5)C 8.0 10 PUR M.I. 10 MAT9841302 (4x(2x0.25)+2x0.5)C 8.5 7.5
PUR M.I. 10 MAT9841318 (4x(2x0.25)+2x0.5)C 8.5 7.5 TPE H* 11 MAT9100034 (4x(2x0.25)+2x0.5)C 8.5 6.8
TPE H* 11 MAT9100001 (4x(2x0.25)+2x0.5)C 8.5 6.8
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
®
®
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
* Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 ASEAN2023 ASEAN2023 igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
®
