Elau/ Harnessed drive cables | Elau/Schneider Electric Harnessed drive cables | Elau/Schneider Electric Elau/Sch-
Schneider neider
Electric Electric
PVC/PUR PVC/PUR/TPE
* Technical information on the cable quality (Code 01-31): Page 578-581 * Technical information on the cable quality (Code 01-31): Page 578-581
Cable quality Part No. Number of cores and conductor Ø R min. Cable quality Part No. Number of cores and conductor Ø R min.
nominal cross section nominal cross section
[mm²] [mm] [x d] [mm²] [mm] [x d]
Elau/Schneider Electric Servo cables Elau/Schneider Electric Hybrid servo cables
Basic cable
Basic cable
E-MO-067
PVC O.I. 04 MAT9750701 (4G1.5+2x(2x0.75)C)C 13.5 10 E-MO-109, VW3E1109Rxxx
PVC M.I. 05 MAT9470001 (4G1.5+2x(2x0.75)C)C 14.5 7.5 PUR O.I. 06 MAT9850706 (4G25+2x(2x1.5)C)C 28.5 10
PUR O.I. 06 MAT9850701 (4G1.5+2x(2x0.75)C)C 13.5 10 E-MO-117, VW3E1117Rxxx
PUR M.I. 07 MAT9470101 (4G1.5+2x(2x0.75)C)C 14.5 7.5 PUR O.I. 27 MAT9850707 5G2.5+(4xAWG24)C+(2x0.25)C 14.5 10
E-MO-092 E-MO-118, VW3E1118Rxxx
PVC O.I. 04 MAT9750704 (4G1.5+2x(2x0.75)C)C 13.5 10 PUR O.I. 27 MAT9850708 5G2.5+(4xAWG24)C+(2x0.25)C 14.5 10
PVC M.I. 05 MAT9470004 (4G1.5+2x(2x0.75)C)C 14.5 7.5 E-MO-119, VW3E1119Rxxx
PUR O.I. 06 MAT9850704 (4G1.5+2x(2x0.75)C)C 13.5 10 PUR O.I. 27 MAT9850709 5G2.5+(4xAWG24)C+(2x0.25)C 14.5 10
PUR M.I. 07 MAT9470104 (4G1.5+2x(2x0.75)C)C 14.5 7.5 E-MO-120, VW3E1120Rxxx
PUR O.I. 27 MAT9850710 5G2.5+(4xAWG24)C+(2x0.25)C 14.5 10
Basic cable E-MO-121, VW3E1121Rxxx
PUR O.I. 27 MAT9850711 5G2.5+(4xAWG24)C+(2x0.25)C 14.5 10
E-MO-087 E-MO-124, VW3E1124Rxxx
PVC O.I. 04 MAT9750703 (4G2.5+2x(2x1.5)C)C 16.0 10 PUR O.I. 27 MAT9850712 5G2.5+(4xAWG24)C+(2x0.25)C 14.5 10
PVC M.I. 05 MAT9470003 (4G2.5+2x(2x1.5)C)C 17.0 7.5 E-MO-125, VW3E1125Rxxx
PUR O.I. 06 MAT9850703 (4G1.5+2x(2x0.75)C)C 13.5 10 PUR O.I. 27 MAT9850713 5G2.5+(4xAWG24)C+(2x0.25)C 14.5 10
PUR M.I. 07 MAT9470103 (4G2.5+2x(2x1.5)C)C 16.0 7.5 E-MO-126, VW3E1126Rxxx
PUR O.I. 27 MAT9850714 5G2.5+(4xAWG24)C+(2x0.25)C 14.5 10
Basic cable E-MO-127, VW3E1127Rxxx
PUR O.I. 27 MAT9850715 5G2.5+(4xAWG24)C+(2x0.25)C 14.5 10
E-MO-111 SH-Motor 1.5 Elau/Schneider Electric Encoder cables
PVC O.I. 04 MAT9750702 (4G1.5+2x(2x0.75)C)C 13.5 10
PVC M.I. 05 MAT9470002 (4G1.5+2x(2x0.75)C)C 14.5 7.5 Basic cable
PUR O.I. 06 MAT9850702 (4G1.5+2x(2x0.75)C)C 13.5 10
PUR M.I. 07 MAT9470102 (4G1.5+2x(2x0.75)C)C 14.5 7.5 E-FB-060
PVC 08 MAT9480001 (4x(2x0.25)+2x0.5)C 8.0 10
Basic cable TPE H* 11 MAT9480101 (4x(2x0.25)+2x0.5)C 8.5 6.8
E-FB-071
E-MO-113 SH-Motor 2.5 PVC 08 MAT9480002 (4x(2x0.25)+2x0.5)C 8.0 10
PVC O.I. 04 MAT9750705 (4G2.5+2x(2x1.5)C)C 16.0 10 PUR M.I. 10 MAT9940702 (4x(2x0.25)+2x0.5)C 8.5 7.5
PVC M.I. 05 MAT9470005 (4G2.5+2x(2x1.5)C)C 17.0 7.5 TPE H* 11 MAT9480102 (4x(2x0.25)+2x0.5)C 8.5 6.8
PUR O.I. 06 MAT9850705 (4G1.5+2x(2x0.75)C)C 13.5 10
PUR M.I. 07 MAT9470105 (4G2.5+2x(2x1.5)C)C 16.0 7.5 Basic cable
E-FB-080
PVC 08 MAT9480003 (4x(2x0.25)+2x0.5)C 8.0 10
PUR M.I. 10 MAT9940703 (4x(2x0.25)+2x0.5)C 8.5 7.5
TPE H* 11 MAT9480103 (4x(2x0.25)+2x0.5)C 8.5 6.8
Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image. Note: The given outer diameters are maximum values and may tend toward lower tolerance limits. Example image.
®
®
igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core igus gladly pre-harnesses the cable according to your technical guidelines. G = with green-yellow earth core, x = without earth core
* Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant * Cable qualities: M.I = with inner jacket, O.I. = without inner jacket, F = flame-retardant, H = halogen-free OIL = oil-resistant
®
®
igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961 ASEAN2023 ASEAN2023 igus GmbH defines cable length as entire length including connectors or open harnessing. Page 961
